8X1 Satellite Diseqc Switch 8 in 1 out Diseqc Switch
| US$1.60-4.50 | 100 Pieces (MOQ) |
Basic Info.
Model NO.
BT-08A
Condition
New
Frequency Range
5-2400MHz
Ways
2/3/4/6/8/16ways
Material
Zinc Die-Cast Housing, Tin-Plated
Transport Package
Standard Exported Package
Specification
31.8*29*21cm /100pieces/10.4Kg
Trademark
BOTE
Origin
Hefei, Anhui, China
HS Code
8529901090
Production Capacity
200000PCS Per Month Per Type
Product Description
8x1 satellite diseqc switch 8 in 1 out diseqc switchProduct features:Zinc die-cast housing, tin-platedLight weight and compact sizeEasy installation with two edge hole sitesScreening factor: 5-2400MHz≥100dBLow insertion loss, high isolation, perfect performance indexDesigned for SATV/CATVPower passing-24V 0.8A(MAX.)All ports F-(f)connector,75Ohm8 ways SATV/CATV splitter Parameter description:
Frequency Range (MHz) | Insertion Loss(dB) | Mutual Isolation(dB) | Return Loss(dB) |
5-40 | ≤8.0 | ≥22 | ≥10 |
40-1000 | ≤8.5 | ≥22 | ≥12 |
1000-1750 | ≤9.5 | ≥20 | ≥12 |
1750-2400 | ≤11.0 | ≥20 | ≥10 |
