Wood Based Panel Machinery: OSB MDF HDF Particleboard Chipbaord 40 Layers Hot Press with Automatic Loading&Unloading
| US$6,000.00-100,000.00 | 1 set (MOQ) |
Basic Info.
Model NO.
MH-OSB400
Product Type
OSB Production Line
Automatic Grade
Semiautomatic
Power Source
Electric
Screw Design
Double-Screw
Certification
CE, ISO
Condition
New
Customized
Customized
Name
Pb Production Line
Machine Included
The Full Complete Production Line
End Product
Particle Board
Particle Board Size
4*8feet or Customized
Panel Thickness
10-30mm
Daily Capacity
100-400cbm
Yearly Capacity
30000-180000cbm
Machine Color
Be Customized
Transport Package
None
Specification
4*8feet or customized
Trademark
MINGHUNG
Origin
Linyi City, China
HS Code
846592
Production Capacity
10 Sets /Year
Packaging & Delivery
Package Size
600.00cm * 230.00cm * 260.00cm
Package Gross Weight
10000.000kg
Product Description
Product Description
| Drum Chipper | |
| Inlet size | 240*750mm(H*W) |
| Blade quantity | 2pcs |
| Knife roll diameter | 800mm |
| Power | 132kw |
| Triple Pass Drying Machine | |
| Cpacity | 10000kg/h |
| Original moisture | ≤80% |
| End moisture | 2% |
| Power | 440kw |
| Forming machine | |
| Surface forming machine | 2 sets |
| Capacity | 2 *45m3/h |
| Core forming machine | 1 sets |
| Capacity | 65m3/h |
| Forming width | 1300mm |
| Forming thickness | 30-120mm |
| Continuous press | |
| Convey speed | 10-30m/min |
| Working height | 1250mm |
| Belt width | 1500mm |
| Power | 75kw |
| Hot press | |
| Pressure | 1200 ton |
| Hot plate size | 2650*1680*120mm |
| Layers | 22 |
| Heating medium | Oil |
| Heating temperature | ≤180ºC |
| Closing time | 10s |
| Edge trimming saw | |
| Suitable final board | Particle board, MDF, OSB, Plywood |
| Panel size | 4*8feet or be customized |
| Working way | Automatic |
| Panel thickness | max 60mm |
| Weight | 15to |
| Sanding machine | |
| Max sanding width | 1300mm |
| Sanding thickness | 3-50mm |
| Sanding belt size | 1350*2800mm |
Working Process
