Ecoographix Offset Aluminum Processless Negative Thermal CTP Printing Plate

Product Description

Product DescriptionECOO-G thermal DOP plate (develop on press ), could be applied onto press machine directly without processing/developer after imaging, chemistry free, environment-friendly, as same as Sonora XP.
ECOO-G is well sold in Europe, USA, Canada. It is like Kodak Sonora and Agfa Azura. It meets the trend of being environment-friendly and has bright future. This plate can be applied on printing machine directly without processing and developing. So it saves cost of labor, water treatment and developer tank. Hope you like it.
ECOO-G contrast before and after imaging
Product Parameters

Model	Ecoo-G
Plate type	Non-ablation thermal-Negative type
Application	High grage commercial and newsprinting
Substrate	Electrolyte graining and Anodozed AL substrate
Thickness	0.15mm-0.4mm
Spetrum scope	800-850 nm
Plate setter	Various dominant thermal platesetters in the market
Low-energy imaging	130-150 mj/m²
The period of latent image stablization	≤7 days
Recommended screen method	1-99@ 200 lpi AM/20U FM and mixture
The paper number of start-up	< 50 sheets
Safety light	1 hour under fluorescent lamp, no direct irradiation with natural light, 4 hours under yellow light.
Processing	Without processing, directly on press
Run length	100000 impressions, actual run length depend on printing conditions
Baking	No recomended

Our AdvantagesFeatures
High-quality aluminum substrate and unique-grain processing technology. The substrate grain is uniform fine, which ensures the exact dot reproduction and excellent printing adaptability of the printing plate.
The professional formula design with infrared laser sensitive phase- change layer ensures that the plate can be put on press directly after exposure.
High sensitivity , wide tolerance, screen dots with margin sharpness
Excellent printability, fast-inking balance, suitable for high-grade commercial and packaging printing.
Compatible with various dominant thermal platesetters in the market, suitable for manual and automatic loading system.
Bright room operation in which people can operate safely under fluorescent lamp.
Stable quality.
A variety of the plates provided with thickness from 0.15mm to 0.40mm.
Application
Suitable for sheet-fed offset press or high speed rotary offset press.
Run length: 100000 impressions
Suitable for different types of traditional inks and fountain solutions, including alcohol's substitutes as fountain solutions.
Unsuitable to improve run length by baking plates.
Processless plate V.S normal process plate

ECOO-G	V.S	ECOO-ED/ECOO-ES
(Thermal Negative Processless plate )		(Thermal positive process plate)
No processor requires, save your cost on processor machine		A processor machine required
No chemistry to deal with, save your cost on developer and water treatment		Developer required
Elimination of processing time, more time available for other work		30 seconds in processor per sheet
Same performance level as Azura & Sonora, but more competitive price		/
Environment-friendly product, has bright future, policy support		Need extra water treatment device and space to treat wasted developer
Higher price than normal process plate		More economic in price, lower business cost
20 pcs of starting papers until image come out		less waste in starting paper
Not strong contrast between imaging zone and non-image zone, not easily to recognize image mistake before printing		Strong contrast after imaging is helpful to observe image mistake

Product detailsECOO-G is double layer, and the emulsion layer will not dissolve into water, so it will not integrate into fountain solution; while the protection layer is well water-soluble, and it will be easy dissolved into the fountain solution.
Plate making procedure

CTP model Data	Kodak trendsetters	LOTTEM 400(TH1.7)	MAGNUS 400	Screen 8600S
Laser power	15-17W	300-320mw	19.5-21.5W	80-90 %
Drum speed	250-300rpm	850-900rpm	400-450rpm	800-900rpm
Resolution	Customized	Customized	Customized	Customized
Parameter that need set up	Focus/ Zoom	Focus/ Zoom	Focus/ Zoom	Focus/ Zoom

FAQ1. How long is the lead time?
The lead time is normally 45 days.
2. Do you offer free plate samples?
Yes, we offer free testing samples maximum 12 pcs for each size but with delivery fee to collect.
3. How do you guarantee stable quality?
There are 3 inpecting procedures: 1, automatic on-line 24h scanning detector; 2, random sampling per 15 mins at the producing line; 3, manually full inspection before packing. The production is mature. It is not a new product to us.
4. Do you have accompanying plate making products to enable one-stand easy purchase for some end users?
Yes. CTP machine, processors, violet plate, CTP-CTCP plate, chemistry(fountain solution, roller wash, etc.) are all available to make your purchase more easily.
5. Payment term?
Normally, 30% deposit, 70% before shipping, or LC at sight.
6. Is refrigerating container necessary for shipment?
No. The plate is relatively stable and mature. So normal container is enough unless some ertreme hot situations.
7. How to use this processless plate?
Clean all the inks on the blanket;Start the press machine, apply the water roller, run 15-20seconds;Apply the ink rollers 20-30 seconds;Apply the paper and start print.Factory
