Nonwove Velour Loom Needle Punching Machine with Good Service

Product Description

Nonwove velour loom Textile Machine with Good Service
Product Description
YYQR-RANDOM VELOUR NEEDLE LOOM

Function and Characteristics:
The purpose of random velour machine is to make a pile effect on the surface of a nonwoven substrate for enduses such as automotive, floor covering, wall covering and felt for toy etc.

Main specification

Raw material	Synthetic fiber such as Polyester, Polypropylene, etc
Product weight	300-800 gram/ m2
Working width	2000mm, 2500mm, 4400mm
Needle Density	5000n/M*2
Needle stroke	35mm
Needle frequency	2000s/Min

Characteristics
High precision double crank shaft system drives high strength needle punching system made of aluminum alloy. Central oil lubrication circulation and cooling system complete with pressure and temperature alarm systems. High quality long service life brushes, rails and drive chains are imported from the best supplier. They are fitted into a unique brush conveyor system which offers a perfect penetration base for a clean smooth material surface during running.
Right brush stripping point with mark free. Equipped with special cleaning system and dust collection system. Siemens control System. Using SEW Eff motor and SEW reducer, all the electrical components are CE standard. The whole machine utilizes PLC interface by touch screen and production parameters clearly displayed on HMI to make operating parameters easy to change, and parameters can be saved. Using the best bearings and Air cylinder. Painted with electrostatic powder and heated with high temperature which makes the painting more strong.
Latest Industrial design
Main products

Main production line
Geotextile production line	Acoustic fiber board production line	Automotive interior nonwoven production line	Synthetic leather substrate production line
Thermal bonded wadding production line	Through -air bonded nonwoven production line	Spun-bonded nonwoven production line	Spun-laced nonwoven production line
Filter felt production line	Needle punched wipe production line	Scrubbing pad nonwoven production line	Comforter filling production line
Airlay felt nonwoven production line	Glass fiber production line	Jute felt needle punched production line	Geo-synthetic clay liners lamination production line
