Automatic Metal TCK50 Horizontal Metal Slant Bed CNC Lathe
1. The TCK-50 model embraces an innovative design with a 45° inclined layout and an integrated bed base structure, significantly enhancing the machine's bending and torsional rigidity. It boasts high rigidity and exceptional stability, providing a robust guarantee for superior performance.2. The TCK-50 Spindle Unit is crafted with precision, featuring high-accuracy NSK spindle bearings. This meticulous assembly ensures remarkable rigidity and unparalleled performance. Thanks to a stringent dynamic balance test, the spindle system excels with outstanding accuracy, superb accuracy retention, minimal thermal deformation, and impressive thermal stability, achieving top speeds up to 2600rpm.3. Outfitted with a hydraulic knife tower, the TCK-50 offers users a seamless and reliable solution for processing intricate parts efficiently.4. With a comprehensive hydraulic and lubrication system, the TCK-50 employs premium quality components, including a high-grade hydraulic pump and valves, significantly minimizing the risk of failure. The system is designed for simplicity and reliability, featuring centralized automatic lubrication to ensure optimal performance.5. The integration of an elastic coupling between the driving motor and ball screw ensures transmission without clearance, offering high precision and safeguarding the machine tool effectively.6. Utilizing a servo main motor, this machine enables stepless speed regulation for smooth operations. It excels in providing constant linear speed cutting, yielding parts with superior surface quality.
Detailed Photos
TCK-50 CNC lathe features a robust box structure bed made from high strength Mihanna cast iron. Its compact structure offers excellent strength, optimal hardness, low friction, and self-lubrication. The integral box structure of the base bed significantly amplifies the machine's rigidity and stability. It efficiently absorbs vibrations, reduces tool wear, and enhances workpiece quality. The TCK-50 presents a high performance-price ratio, boasting a compact and logical layout, high speed, precision, rigidity, and rich configurations, ensuring high efficiency and reliability for users.
Product Parameters

Specification	TCK50	TCK56	TCK600	TCK1000	FCK56
Max. swing diameter on the bed (MM)	500	560	600	560	650
Max. cutting diameter (MM)	360	330	550	350	530
Max. cutting length (MM)	500			1000	540
X-axis travel(MM)	200		280	200	280
Y-axis travel(MM)	±50
Z-axis travel	550	450	550	1050	750
X-axis moving speed (M/MIN)	30
Z-axis moving speed(M/MIN)	30
X-axis positioning accuracy	0.008mm
X-axis repeatability	0.005mm
Z-axis positioning accuracy	0.008mm
Z-axis repeatability	0.006MM
Spindle speed(RPM)	50-4500		50-3500	50-4500	50-4500
Main motor power	11kw
Main motor torque	72N.M
Weight (KG)	3600	4500	4300	4500	4200
