Active Rotary Kiln Lime Furnace Making Machinery Cement Production Plant

Product Description

Product Description
Description of Lime Vertical / Shaft Kiln:
Lime is used for producing cement for the construction industry. Lime is very important fir many other uses and chemical applications, to produce gypsum wallboard or drywall panels, to neutralize toxic chemicals, for air pollution control scrubbing systems, for neutralizing the acidity of soil for agricultural, and Vertical Lime Kilns are used for the production of sugar. Lime is used for pigment in paints.

Working Principle of Lime Vertical / Shaft Kiln:
Large 1,000+ ton/day capacity Vertical Lime Kilns are possible, are very energy efficient and easy to operate. Minimal maintenance is required, because the limestone is brought to the top and into the kiln. Then the limestone is burned (calcined) for a specified time of hours to produce powdered lime. Then the lime is withdrawn at the bottom of the vertical kiln. The withdrawal at the kiln bottom regulates the gravity flow of limestone and controls the calcining retention time in the kiln. A clinkergrinding mill grinds any remaining chunks of limestone into powder. The lime is then transported by truck trailers or by rail cars. White cement is now very much in demand by the construction industry.
Product Parameters

capacity (t/d)	effective volume (m3)	effective height (m)	effective section dia. (m)	feeding size (mm)	heat consumption (kJ/kg)	CaO (%)	availability of lime (mL)
100	98	20	Ø2.5	30~60/40~80	<4600	>90	>300
120	141	20	Ø3.0	30~60/40~80	<4600	>90	>300
150	202	21	Ø3.5	30~60/40~80	<4500	>90	>300
200	301	24	Ø4.0	30~60/40~80	<4500	>90	>300
300	397	25	Ø4.5	30~60/40~80	<4400	>90	>300
400	491	25	Ø5.0	30~60/40~80	<4200	>90	>300
500	735	26	Ø6.0	30~60/40~80	<4200	>90	>300

Packaging & Shipping
We have developed long and good relationship with many shipping agents. Ocean freight partners are: APL, COSCO, OOCL, CSCL, MSC, etc. and train shipping is also available. The perfect shipping way and best service with lowest price are always provided for customers.
Company Profile
Shandong Tianhang Machinery Equipment CO.,LTD is a new high-tech private enterprise attached to Shandong Tianhang Group. It has more than 150 employees, including 52 engineering technicians,34 with Intermediate Certificate. Covering an area of more than 22,000 square meters, the company is composed of machining, riveting welding, assembly and other workshops. With 110 sets of advanced equipment, advanced processing equipment, large processing range, high precision products. Since the establishment of the enterprise, the implementation of high starting point, high quality strategy, in China, we have finished equipment intelligent transformation and technical optimization to kind of complete project fromφ3200 toφ5300 vertical lime kiln ,its performance reliable, quality reliable, operation simple. With its advantages of advanced technology, reliable quality, considerate service and favorable price, Tianhang has become a lime kiln equipment manufacturing base, and products are sold all over the world and widely praised.
Our company has many projects at home and abroad, such as Serbia Zijin Boer Copper Co.,Ltd,Pakistan Olympia Chemicals Co.,LTD,and now we are working on a 300 ton/day lime kiln project of Kyrgyzstan South Building Materials Co., LTD.We have the strength and confidence to provide quality kilns for lime cement clinker and calcium hydroxide manufacturers all over the world.

Our Product
Certifications
Our Advantages
1.Save energy2.The shell of kiln use four layer refractory in vertical masonry, good effect of thermal insulation.
3. Long service life of refractory
4. Less cover area
1.Pre-sales Service
Offering comprehensive technical and business consultation services;
Proposing th e most suitable scheme and equipment for our clients;
Designing and fabricating targeted products according to the special requirements of clients;
Training periodically high qualified service technician.
2.After-sales Service
Highly inspecting equipments in every working procedure, quality comes first;
Fast & Safe Delivery;
Assisting our clients for foundation construction of equipments;
Dispatching engineers to install and debug equipments;
Training the first-line operators on site;
Regularly visit clients to solve production problems;
Providing life-long maintenance service;
Providing technical exchanging;
FAQ
1.Why us?We provide professional industrial furnace and industrial design as customer order. 2.How is the quality of your products?Our products are manufactured strictly according to national and international standard, and we take a test on every product before delivery.3.Guaranteed?If products' quality is not consistent with the description as we described or the promise before you place order, we promise 100% refund.4.How about price?Yes, we are factory and be able to give you the lowest price than market one, and we have a policy that " for saving time and absolutely honest business attitude,we quote as low as possible for any customer, and discount can be given according to quantity".
