Brush Ferrule Machine Wood Brush Making Machine

Product Description

-- PRODUCTION DESCRIPTION --
-- PRODUCTION SIZES --
Detailed parameters of the equipment
1.Designed by 2 drillings and 1 tufting,equipped with 3 stations 3 or 6 fixtures machine works in continuous cycle, high efficiency. 2.Optional round flat or roller platforms for different types of brushes. 3.Touch screen control system,Chinese and English version, flexible and convenient operation. 4.Support synchronous drilling and tufting, single drilling, single tufting and other processing modes. 5.Single color and double colors are optional. 6.With insert,division, arrayoffset,modify and other functions, easy to program. 7.Can save 1000 different brushes programs, support external USB. 8.Tufting accessories are standardized designs, achieve multi-process finishingbeautiful and durable. 9.Automatic oil lubrication system,regularly and automatically lubricate the parts with high frequency operation,reduce wear and tear.

MODEL	FM-130P-TG3	FM-180P-TG3L
Axes	5	5
Fixture	3	3
Tufting Type	Stapling wire
speed	450	420
Length of fiber outside hole (mm)	17~130	17~180
Total length of fiber (mm)	40~270	40~400
Diameter of hole (mm)	2.8~6.5	2.8~8.0
Diameter of fiber (mm)	0.07~1.5mm
Total power (KW)	11	11.5
Voltage(V)	380V/220V	380V/220V

-- EQUIPMENT DETAILS --
Detailed display of the product -- EQUIPMENT SHIPMENT --
Ships three or four times a week on average
-- INSTALLATION & COMMISSIONING --
Provide professional technicians for overseas debugging
-- SUCCESS CASE --
Complete production line
-- FUTUER TEAM --
About Foshan Futuer Machinery Co., Ltd.
