High-Efficiency Growatt Hybrid Inverter 6000W MPPT for Solar System with Good Price

Product Description

Product Description
Product Parameters

MODEL	SOL IA6000-D1
Battery
Battery Voltage	48VDC
Floating Charge Voltage	54VDC
Battery Type	Litium/Lead-acid
Inverter Output
Rated Power	6000VA/6000W
Parallel Capability	Yes, 6 units maximum

AC Voltage Regulation(Battery Mode)	230VAC+-5%@50/60Hz
Surge Power	12000VA
Efficiency(Peak)	93%
Waveform	Pure sine wave
Transfer Time	10ms typical, 20ms Max
Solar Charger
Maximum PV Array Power	8000W
MPPT Range&Operating Voltage	120VDC~450VDC

Number of Independent MPP Trackers/Strings Per MPP Tracker	1/2
Max.input current per MPPT tracker	16A
Maximum PV Array Open Circuit Voltage	500VDC
Maximum Solar Charge Current	100A
AC Charger
Charge Current	80A
AC Input Voltage	230VDC
Selectable Voltage Range	170-280VAC(For Personal Computers); 90-280VAC(For Home Appliances)

Frequency Range	50Hz/60Hz(Auto sensing)
Physical
Protection Degree	IP20
Dimension(W*H*D)	460*395*132mm
Net Weight(kgs)	13.5
Communication Interface	USB/RS232/RS485/WIFI/Dry-contact(optional)
Operating Environment
Overioad Capacity	110%

Humidity	5% to 95% Ralative Humidity(Non-condensing)
Altitude	<2000m
Operating Temperature	0 degree centigrade~55 degrees centigrade
Storage Temperature	-15 degree centigrade~60 degrees centigrade

Company Profile
Certifications
Customer Feedback
FAQ FAQ
Q1: Is the output voltage of our inverter stable ?
A: Absolutely. Our inverter is designed with a good regulator circuit. You can even check it when measuring the true value by a multimeter. Q2: What should be noticed when installing inverter?
A: Put the product in a place where is well ventilate,cool, dry and water-proof. Do not stress or put foreign objects into the inverter. Remember to turn on the inverter before turn on the appliance. Q3: Can I get some samples for test? A: Yes, sample order is available for quality check and market test . Q4: Do you accept OEM/ODM ?A:Yes, we accept OEM/ODM with your authorization. Q5: How is delivery time? A: Generally it takes 5-10 days for regular type , for big quantity or OEM/ODM orders, pls negotiate with sales. Q6: What's your payment terms? A: We accept T/T, L/C, WEST UNION, ALI TRADE ASSURANCE, cash. Q7: What's your warranty time? A: We offer 18 months warranty service, life time technique support. Q8: How does your factory do the quality control? A: Quality is our culture. We have strict quality control department to supervise each link from assembling to shipping. Q9: How can I trust you ? A: CKMINE has 16 years' experience in producing inverters, we have passed ISO9001 management system and got CE, CCC certificates. Assessment reports can be sent anytime if you require.
