Hydrostatic Testing Machine, Hydraulic Pressure Testing for Spiral Welded Pipe

Hydrostatic Testing Machine, Hydraulic Pressure Testing for Spiral Welded Pipe

US$150,000.00-350,000.00 1 Set (MOQ)

Basic Info.

Model NO.
HYSY1220
Pipe Material
Carbon Steel
Condition
New
Customized
Customized
Application
Industry
Type
Pipe Mill
Pipe O.D.
508-1220mm
Length
8-12m
Capacity
75kw
Max. Testing Pressure
1000t
Pipe Wall Thickness
Max. 12mm
Pipe Weight
Max 25 T
Tensioning Beam Type
Rectangle Section Four-Stretching Beam
Transport Package
Nude
Trademark
HUAYE
Origin
China
Production Capacity
5-10sets/Year

Packaging & Delivery

Package Size
150.00cm * 100.00cm * 100.00cm
Package Gross Weight
50.000kg

Product Description


Hydrostatic testing machine for spiral welded pipe
Introduction
Hydrostatic testing machine for spiral welded pipe is mainly used to have a pressure test on spiral welded pipe or straight seam welded pipe. This hydrostatic tester uses water to inspect whether the steel has been welded properly or not, whether the steel is flawed or not and also what will be the maximum pressure that the stainless steel can sustain. There are three different testing sizes as light size for small tube, medium size and heavy size for large diameter pipe.
Equipment List
Hydraulic tester body
Main hydraulic cylinder
Hydraulic system
High & low pressure water systems
Electrical control system
Pre-buried and anchor bolt
Recording system with computer
Socket and spigot sealing mould
(Sealing and expanding)
The major factors to determine the model a hydrostatic tester is listed as below.
Pipe diameter range
Max test pressure
Max test pressure at maximum pipe diameter
Pipe wall thickness
Pipe end finish (plain or beveled)
With these information, our experienced engineers will be able to determine the machine type, max hydraulic power, sealing type etc.
HUAYE has rich and deep technical accumulation to design various types of hydrostatic tester for the customer. No matter it's for extra large diameter, extra high pressure, extra-long length, or extra fast speed, HUAYE provides satisfying solution at most budgetary price.
HUAYE with Customer
Loading and shipping
