High pressure ceramic materials briquette machine / Ceramic materials powder ball press machine / briquetting machine

Product Description

Product Description
Product IntroductionHigh pressure ceramic materials briquette machine/ ceramic ball press machine / briquetting machine Ceramic material briquette machine also named ceramic material briquette press machine, ceramic powder ball press machine,ceranic powder briquetting machine etc. The ceramic material Briquette Machine mainly applies on the briquette making of ceranic material and ferrous metal mineral powder, it enters the furnace directly to increase the additional value. All metallurgy industry waste and accessory that need furnace use ball briquetting machine. Such as dedusting ash, pool mud, oxide, slag, iron flavor powder,aluminum ash powder, silicon manganese ore powder, etc. Pressed powder materials into a ball to reduce dust and facilitate transport. Such as iron powder, charcoal, clay, coke breeze, coal, lime powder, etc.Product ParametersTypeDiameter(mm)Roller Width(mm)Power(kw)Capacity(kg/h)LYQ 0.5Φ29918018.5500LYQ 1.0Φ367183371000LYQ 1.5Φ367183451500LYQ 2.0Φ399.5252452000LYQ 3.0Φ522196553000LYQ 5.0Φ700-738210/225755000LYQ 6.0Φ738225906000LYQ 8.0Φ7582251108000LYQ 10Φ85830011010000Working PrincipleCeramic material Briquette Machine Working PrincipleCeranic material Briquette Machine will pass raw powder on to the two pressure roller through the reducer. The two sides and roll rotation, in both the rotating roll, raw powder enter the ball roll mode, with the roll rotation, raw powder pressure on a small become larger, when raw powder to the two rollers rotating line contact point, the pressure of raw powder has reached the peak. Tremendous pressure in the role of line, the ceramic powder becomes briquette.Product Details ShowCeramic material briquette machine requirment of raw material 1. Material size about 80 to 200 mesh.2. Materials are not allowed has hard metal objects to avoid damaging the pressure roller.3. Return materials should not have too much clumps(≤3mm), return materials is not more than 50% in the feeding materials. 4. Supply of materials must be sufficient, use variable speed screw feeder is better. Machine UsageCeramic material briquette machine main usageCeramic material briquetting, coal molding, dry powder molding, Desulfurization gypsum molding, coke powder molding, aluminite powder briquetting, Scrap iron and various metal mineral powder molding ,lime powder briquetting etc.Other material use ceramic material briquette machine Coal powder, coking coal , aluminite powder, scrap iron, oxidation iron sheet, carbon powder,mineral waste residue, gypsum, tailings, sludge, kaoline, activated carbon, coke breeze and all kinds of powder, powder lot, waste material ,waste residue. Widely used in refractory material, power plants, metallurgy, chemical industry, energy, transportation, heating, etc.Hydraulic SystemWorking SiteCompany Profile
