Cdada AC Type 18mm Dpn 16A 20A 32A RCBO Circuit Breaker CB Approved Factory Price

Product Description

Introduction Installation method: Effortlessly mount on a 35mm guide rail, ensuring full compliance with stringent IEC standards. Experience unparalleled safety, reliability, and ease of installation with our meticulously engineered system.
Terminal type: Featuring versatile dual-purpose terminals, our product offers seamless connections to both bus bars and conductors, significantly enhancing installation flexibility and efficiency.
Terminal connection ability: Accommodates a broad range of conductor sizes, from 1mm to 25mm, providing exceptional versatility and adaptability to various installation requirements.
2
Bus bar thickness compatibility: Expertly designed to fit bus bars with thicknesses ranging from 0.8mm to 2mm, ensuring optimal performance and secure connections in all applications.
Guide rail: Employs a robust DIN35 guide rail, guaranteeing secure, stable, and durable installation for long-lasting performance.
Functions of DAB7LN-40 residual current circuit breaker: Delivers comprehensive protection and isolation, effectively safeguarding your electrical systems against potential hazards and ensuring continuous operation.
Key Features: Equipped with reliable short circuit protection, efficient overload protection, and effective isolation. Our product ensures utmost safety, superior performance, and peace of mind.
Electrical parameters of DAB7LN-40 residual current circuit breaker:

Number of poles		1P+N(18mm)
Rated frequency		50-60HZ
Rated operating voltage		230V
Rated current		40A
Rated insulation voltage		500V
Impulse withstand voltage		4KV
Instantaneous trip type	DAB7LN-40	B/C
Rated breaking capacity	DAB7LN-40	6
Release type		Thermo-magneti
