Semi Automatic Magnesium Rod Peeling Machine for China Factory

Product Description

Production Information Series WXC Centerless Lathe is a high-efficiency lathe which is specialized in rough processing and finishing of the surface of slender shaft. Not only quickly remove surface hardened layer, cracks and other defects, but also can get high precision.
The machine suits for processing bars and wire rods.
Series WXC Centerless Lathe includes semi-automatice hydraulic type and CNC type.
Production Show
1.Automatic loader and unloader
2.Hydraulic system and Air/oil lubrication system
Technical Parameters

Material	Diameter Range(mm)	Φ37~Φ135X2800~6000
	Yield Strength σb(Mpa)	≤1000
	Surface Hardness	≤HB320
	Original Curvature	≤1 .5
	Diameter Tolerance	According to GB 702-88, 2 group
	Roundness	≤50% of the diameter tolerance
	Surface Roughness(Ra)	≤25~50mm
After Peeling	Diameter Range(mm)	Φ35~Φ130
	Radius Cutting Depth(mm)	1~2.5
	Diameter Tolerance	≤h9(standard tolerance grades)
	Surface roughness(Ra)	≤3.2μm
	Roundness	≤0.03
Main Motor Power(kW)		110(6 poles)
Total Capacity(kW)		130

Company Information YANTAI HAIGE MAHINE TOOLS CO., LTD is mainly engaged in producing and selling bar peeling machines, straightening machines, polishing machines, auxiliary machines and other steel processing and finishing equipment for more than ten years.
Our products are at the top-level in this field in China. We have specialized R&D team who provide solid technical support and guarantee for our machines to keep technology leadership all the time. So far, we have produced and sold more than 1500 sets of equipment. Both the production quantity and market share rank the first in China.
Our company can provide perfect after-sale service and technical suppport all over the world. Till now, our products have been exported to Russia, Korea, India, Vietnam, North Korea, Pakistan, Taiwan, etc.
Certificates
After-sale Service System
1. Free quality guarantee period for 12 months
2. Free long-term technical support
3. Free train for buyer's operator in our factoty
4. Fast response service within 24 hours
5. Our engineers can offer overseas service, including guiding intallation, commissioning, training, etc.
