Cummins 20-2000kVA Diesel Generator with Global Warranty

Cummins 20-2000kVA Diesel Generator with Global Warranty

US$2,000.00-200,000.00 1 Set (MOQ)

Basic Info.

Model NO.
KPC22-KPC2200
Type
Basic Diesel Generator
Installation Method
Fixed
Stroke
Four Stroke
Cooling Method
Water Cooling
Output Type
AC Three Phase
Speed
HSS
Conditions of Use
Land Use
Usage
Common Units, Standby Unit, Emergency Crew
Landuse Type of Unit
Low Noise Automation Type
Excitation Mode
AC Rotating Exciter
Certificate
CE ISO SGS Soncap TUV
Voltage
380V/220V 400V/230V 415V/240V 480V/277V 220V/127V
Current
30A - 3039A
Engine Model
4b3.9-G11 - Kta50-G9
Transport Package
Plywood Case
Specification
1710x700x1340mm - 7000x2300x2650mm
Trademark
Kanpor
Origin
Fujian, China(Mainland)
HS Code
8502110000
Production Capacity
300PCS Per Month

Product Description

1. GENERATOR DATA
Voltage Available:
50Hz: 380-400-415V/220-230-240V;
60Hz: 220-380-416-440-480V/110-208-220-240V
Any special voltage is also available as client's request
Prime Power:
Comply with GB/T2820-97(eqv.ISO8528).
Genset can run unlimitedly under certain power range.
One hour 10% over load in every 12 running hours is allowed;
Standby Power:
standby power is the limit value of maximum output for emergency use.
It is off-oil power,overloading is prohibited
2. MAIN SPECIFICATION
Technical Data
Genset Model KPC25 KPC27.5 KPC33 KPC40
Rated Power KW/KVA 18/23 20/25 24/30 30/38
Standby Power KW/KVA 20/25 22/27.5 27/33 32/40
Rated Voltage V 220V/127V 380V/220V 400V/230V 415V/240V 480V/277V 600V/346V
Speed RPM 1500/1800
Rated frequency Hz 50/60
Engine Model 4B3.9-G1 4B3.9-G1 4BT3.9-G1 4BT3.9-G1
Engine Power KW 27 27 40 40
Air intake way Natural Natural Turbo Turbo
Governor Mechanical Mechanical Mechanical Mechanical
Cylinder QTY 4 4 4 4
Bore*Stroke mm*mm 102×120 102×120 102×120 102×120
Displacement L 3.9 3.9 3.9 3.9
Fuel Consumption g/kw.h 228 228 214 214
Compression Ratio 16.5:1 16.5:1 16.5:1 16.5:1
Alternator Model STF-184E STF-184F STF-184G STF-184H
Voltage Regulation AVR
Excitation Method Brushless
Open Type Size mm 1710x700x1340 1710x700x1340 1800x700x1340 1800x700x1340
Open Type Weight kg 800 830 900 920
Soundproof Size mm 2100x1000x1200 2100x1000x1200 2100x1000x1200 2100x1000x1200
Soundproof Weight kg 1100 1150 1200 1280
Technical Data
Genset Model KPC1375 KPC1500 KPC1650 KPC1718
Rated Power KW/KVA 1000/1250 1100/1375 1200/1500 1250/1560
Standby Power KW/KVA 1100/1375 1200/1500 1320/1650 1375/1718
Rated Voltage V 220V/127V 380V/220V 400V/230V 415V/240V 480V/277V 600V/346V
Speed RPM 1500/1800
Rated frequency Hz 50/60
Engine Model KTA50-G3 KTA50-G8 KTA50-GS8 KTA50-G9
Engine Power KW 1227 1429 1429 1656
Air intake way Turbo Turbo Turbo Turbo
Governor Electronic Electronic Electronic Electronic
Cylinder QTY 16 16 16 16
Bore*Stroke mm*mm 159×159 159×159 159×159 159×159
Displacement L 50.3 50.3 50.3 50.3
Fuel Consumption g/kw.h 197 205 204 203
Compression Ratio 13.9:1 14.9:1 14.9:1 13.9:1
Alternator Model STF-634G STF-734B STF-734B STF-734C
Voltage Regulation AVR
Excitation Method Brushless
Open Type Size mm 4850x2000x2320 4980x2000x2350 4980x2000x2350 5200x2150x2400
Open Type Weight kg 7800 8200 9500 10000
Soundproof Size mm 6000x2200x2600 6000x2200x2600 6000x2200x2600 7000x2300x2650
Soundproof Weight kg 9800 10800 12300 13600

3. PRODUCT FEATURES
(1) Full control panel with power indicator light and oil light.
(2) Emergency shutdown for low oil pressure and high water temperature.
(3) Large fuel tank ensure continuous running.
(4) Low noise & vibration.
(5) Compact structure.
(6) Reliable performance.
(7) Easy for installation and maintenance.
(8) 50Hz and 60Hz both are available for choice
