Sinotruk HOWO 3000 Liters / 3 Cbm Water Tank Truck with Fire Fighting Equipment /Special Truck for Sale

Product Description

Product Description SINOTRUK HOWO 4x2 LIGHT TRUCK WATER AND FOAM FIRE FIGHTING TRUCK
SINOTRUK light truck chassis is selected and refitted by domestic famous brands. The whole vehicle has excellent working performance, including water tank, foam tank, rear water monitor and other equipment. At the same time, it can be retrofitted with optional hangers, and has complete special tools. It is a star model for fire truck export.
Detailed Photos
Product Parameters

Model:	ZZ1067F341CD165
Cabin:	2080mm, 3 seats , with air conditioner
Engine	ISF3.8 , 154hp, 115KW Euro 2
Gearbox:	WLY653, manual, 6 F & 1 R
Front axle	2700kg, drum brake
Rear axle	7200kg, drum brake
Frame	11/9+7H
Tires	8.25R16 7 pcs (including one spare tire)
Overall dimension	6000*2100*3000mm

WATER TANK
Capacity	1200kg
Material	304 stainless steel
Tank structure	Inlet: 1*DN470,with quick locking/opening device
	Overflow port:1*DN65,overflow valve device
	Drain outlet: 1*DN40, with ball valve
	Water inlet: 1*DN65 connector at both sides

Foam Tank
Capacity	680kg
Material	304 stainless steel
Tank structure	Inlet: 1*DN470,with quick locking/opening device
	Overflow port:1*DN65,overflow valve device
	Drain outlet: 1*DN40, with ball valve
	Water inlet: 1*DN65 connector at both sides

Power system
Pump	CB10/30, atmospheric vehicle fire pump
	Low pressure centrifugal type
	Rated flow:30L/s @1.0MPa
	Outlet pressure:1.0MPa
	Maximum suction depth:7M
	Water diversion device: equipped with sliding vane pump
	Water diversion time: ≤ 50s at maximum suction depth

Fire extinguishing device (on-board fire monitor -- foam fire truck)
Model No	PL8/32 fire monitor
Rated flow	24L/S
Rated pressure	0.8 MPa
Angle	Elevation/depression ≥70° / ≤-30°
Range	Water:≥60m Foam:≥45m
Rotation angle	≥360°

Production Line and Shipping
Company Profile
Main Products
After Sales Service
FAQ 1: Payment: A:30% advance payment after signed the contract, 70% balance should be paid before delivery. We can accept T/T and L/C2. Delivery time: A:25-45 working days after payment is received. According to different trucks models3. How about your product quality? A: The products have passed the ISO, CCC, SGS, BV, and CONTECNA qualification certification. All our spare parts are from the original manufacturers with original part number and and anti-fake label, the quality is 100% guaranteed. 4: How long is the warranty period?A:The warranty of our products is 1 year or 50000km, which comes first
