Plastic Extrusion Hydraulic Screen Changer Melt Filter Manufacturer

Product Description

Zhengzhou Great Machinery Co., Ltd is a company focus on the design and research of hydraulic screen changer, melt pump and extrusion dies. Great is a young company but has a large number of senior technicians, the deep technical background and full of passion work team determine it is standing on a high starting point. We do not just supply you the products, but also provide the solution to solve the problem.
We are committed to provide you the best products with ever improving design, strict production and quality control. Strong professional technical team provides you the perfect pre-sales and post-sales services.
Benifits of hydraulic screen changer
1, leak-free mold operation
2, screen change in a quick time
3, no need to stop the working machine
4, easy operation and save the labor
5, improve the quality and increase the output
Applications
Plastic recycling granulator/pelletizer
Plastic sheet/plate extrusion machine
Plastic pipe extrusion machine(pp/pe/ppr)
Cast film
Blown film
Masterbatch
Compounding
Adhesive
Monofilament
Non-woven fabrics

Type	Screen D&A		overall dimension(mm)				Heating power (KW)	Output (kg/h)
	(mm)	(CM²)	L	W	H	L1
GM_SSP-70	Φ70	38	200	170	240	820	3.5/5.8	80-200
GM_SSP-100	Φ100	78	220	185	280	930	4.5/6.8	150-350
GM_SSP-120	Φ120	113	260	205	320	1010	5.2/7.2	220-350
GM_SSP-150	Φ150	176	300	235	360	1140	6.5/8.5	350-800
GM_SSP-180	Φ180	254	320	245	360	1200	7.6/9.5	550-1250
GM_SSP-200	Φ200	314	360	280	420	1300	8.5/11	650-1500
GM_SSP-250	Φ250	490	450	300	430	1520	9.5/12	800-2500
GM_SSP-300	Φ300	706	520	380	500	1660	11.5/15.5	1200-3500
GM_SSP-320	Φ320	803	560	400	560	1700	13/17.5	1500-4000
Remark: As the above specification is subject to change without prior notice
