Product name | NBG 65-40-200/188 AAF2BESBQQEMW1 |
Product No | 96703916 |
EAN number | 5700837567305 |
Pump speed on which pump data are based | 2920 rpm |
Rated flow | 48.33 m³/h |
Rated head | 36.09 m |
Actual impeller diameter | 188 mm |
Nominal impeller diameter | 200 |
Shaft seal arrangement | Single |
Shaft diameter | 24 mm |
Code for shaft seal | BQQE |
Curve tolerance | ISO9906:2012 3B2 |
Pump version | A |
Bearing design | Standard |
Pump housing | Cast iron |
EN-GJL-250 | |
ASTM class 35 | |
Wear ring | Brass |
Impeller | Brass |
CuZn37Pb | |
Internal pump house coating | CED |
Material code | B |
Code for rubber | E |
Shaft | Stainless steel |
EN 1.4301 | |
AISI 304 |
t max amb | 40 °C |
Maximum operating pressure | 16 bar |
Pipe connection standard | EN 1092-2 |
Size of inlet connection | DN 65 |
Size of outlet connection | DN 40 |
Pressure rating for connection | PN 16 |
Bearing lubrication | Grease |
Pump housing with feet | Yes |
Support block (Yes/No) | N |
Connect code | F2 |
Minimum efficiency index, MEI ≥: | 0.65 | |
Net weight: | 118 kg | |
Gross weight: | 135 kg | |
Shipping volume: | 0.315 m³ | |
Country of origin: | SG | |
Custom tariff no.: | 84137011 |
