M-300 DN80-300mm (3-13Inch) Portable Gate Valve Grinding Machine

Product Details

Product Description

Product Description
M-300 DN80-300mm (3-13Inch) Portable Gate Valve Grinding Machine
Technical Parameter
1) Applicstion:Gate Valve Seat,Gate Valve Core.
2) Grinding scope: DN80~330 (3"-13")
3) Motor power: 1100W
4) Rated Voltages: 220V
5) Min distance of valve seal face: B>55mm
6) Allowed adjustable length: L≤650mm
7) Operating weight: 20kg
1.Machine Diagram of Valve Grinder Machine
/data/upload/ueditor/20180723/5b553de700871.png
1.Main body 2.electric motor 3.power box 4.adjusting bracket 5.screw bolt 6.base escopic boom
8.arm 9grinding disc 10screw bolt 11screw bolt 12 clamping rod 13Fastening handle escopic boom lock arm 15.left or right adjusting handwheel 16.handwheel 17.sliding crame 18.screw bolt
2.Advantages of Valve Grinder Machine
Model M-300 portable valve grinder machine is widely used in the industries such power generation, petroleum, chemical, metallurgy and paper making as a high-tech product with national patent. It has the following characteristics:
1) Light, compact, and easy to carry
2) Split-type assembly makes installation easy and fast
3) Available in various field work
4) Applicable in grinding gate, check valves and flanges made of various materials
5) Grinding automatically after the installation is adjusted well
6)Reasonable structure design, perfect Metabo motor and high-quality imported grinding materials contribute to the grinding 3-10 times as fast as the manual one
7) Stepless and adjustable speed, stable power transmission and accurate lapping make the sealing face in complete contact.
8) Suitable for online repair and offline repair of valves that are inconvenient to disassemble.
3.Technical Parameter of Valve Grinder Machine
1) Application:Gate Valve Seat,Gate Valve Core.
2) Grinding scope: DN80~330
3) Motor power: 1100W
4) Rated Voltages: 220V
5) Min distance of valve seal face: B>55mm
6) Allowed adjustable length: L≤650mm
7) Operating weight: 20kg
4.About us
As a professional Portable Gate Valve Grinding Machine manufacturer, Metals Kingdom Industry Limited is an established company established in 1994, with nearly 30 years of production experience. Products passed ISO quality management certification. Professional technical level and the most favorable price are the most basic guarantees we can provide you. In addition to valve grinder machine, we also manufacture a variety of products such as valve pressure test benches.
If you have any questions or want to know more details, please click here to contact us. You will receive a professional technical consultation reply within 24 hours.
