Single Color PVC Directly Injection Moulding Machine Shoemaking Machinery
| US$25,000.00-35,000.00 | 1 set (MOQ) |
Basic Info.
Model NO.
KK-EFA05
Power Supply
Hydraulic
Function
Shoemaking Line
Screw Rotating Speed
0-72
Max Injection Capacity
580
Shoe Cramp Height
210-260
Total Power of The Whole Machine
20.5
Transport Package
Film
Specification
2000× 2100× 1250mm
Trademark
Kingkung
Origin
China
HS Code
8453200000
Production Capacity
35-50pair/H
Product Description
| Item | Unit | Specification | Specification |
| Color | Single | Single | |
| Number of station | Pcs | 12 | 20 |
| Screw diameter | mm | 75 | 75 |
| Screw rotating speed | r/min | 0-72 | 0-160 |
| Screw length and diameter ratio | 18:1 | 18:1 | |
| Max injection capacity | Cm3 | 580 | 580 |
| Plastifying capacity | g/s | 40 | 40 |
| Sliding platform travel | Mpa | 5.0 | 5.0 |
| Travel for lifting the cramp | Mpa | 3.0 | 3.0 |
| Clamping way | scissors | scissors | |
| Mention last trip | mm | 60 | 60 |
| Shoe cramp height | mm | 210-260 | 210-260 |
| Mould frame dimensions(LxWxH) | mm | 340x180x60 | 340x180x60 |
| Total power of the whole machine | kw | 20.5 | 20.5 |
| Outline dimensions of the whole machine (LxWxH) | mm | 5735x2910x1955 | 6135x3310x1955 |
| Total weight of the whole machine | kg | 4800 | 11800 |
