Conventional Turret type Milling machine 58"X12" large working table Taiwan spindle, OEM
| Negotiable | 1 Piece (MOQ) |
Basic Info.
Model NO.
M4VLW
Structure
Ram
Milling Cutter Type
Vertical Milling Cutter
Milling Cutter Structure
Integral
Controlling Mode
Artificial
Automatic Grade
Manual
Precision
Precision
Certification
GS, CE, RoHS, ISO 9001
Condition
New
Transport Package
Pallet
Specification
1950*1470*2300
Trademark
Hercules
Origin
China
HS Code
8459699000
Production Capacity
2000sets/Month
Product Description
Conventional Large table Milling machineTable size: 1470*320mm (58" * 12") X axis travel 1000mm, Y/Z axis travel 400mm which is much longer than standard M4VB; our casting is double layer, with square guide way, this improves the casting's rigidity, and the square guide way could keep entire machine more stable during processing metal pieces, also ensure the precision when the knee moving up and down; Y axis is square guide way, its load-bearing and guiding performance are much better than dovetail; After enlarge the table size to 1470*320mm, we also make the saddle and knee larger accordingly, the cross and vertical guide way are full covered, so when move the table to one side end, it well prevents entire machine to overturn, and keep the working precision better.
and here is the specification:
| Model | M4VLW |
| Precision High Accuracy Series | |
| Table size(L*W)(mm) | 1470x320 |
| Max.load of table (kg) | 300 |
| X axis(mm) | 1000 920 with power feed |
| Y axis(mm) | 400 |
| Z axis (mm) | 400 |
| Work table T slot (No.-size*pitch) (mm) | 3-15.88x65 |
| Distance between spindle and table(mm) | 50-450 |
| Ram travel (mm) | 520 |
| Travel of spindle quill (mm) | 127 |
| Auto crossward feed(mm/rev) | 0.04/0.08/0.15 |
| Spindle speed(rpm)(60Hz) | 80-5440 rpm 16steps |
| Spindle hole taper | R8 / ISO30 / ISO40 (optional ) |
| Main Motor | 3HP |
| Tilt angle for milling head | left and right±90º forward and backward±45º |
| Guiding tracks(X.Y.Z) | X axis dovetail, Y&Z axis square guideway |
| Dimension(L*W*H)(mm) | 1950x1670x2150 |
| Milling head | Round step milling head |
| Weight (kg) | 1400 |
Pictures for reference only:
