Double Position CNC Milling Machine Horizontal Machining Center Hmc500APC
| US$80,000.00-150,000.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
HMC500APC
Type
Horizontal Machining Center
Object
Metal Milling
Structure
Desktop
Milling Cutter Type
Face Milling Cutter
Milling Cutter Structure
Indexable Type
Controlling Mode
CNC
Automatic Grade
Automatic
Precision
Normal Precision
Certification
CE, RoHS, ISO 9001
Condition
New
Spindle
Taiwan
Leadscrew
Taiwan
Rotary Table
Taiwan
Controller
Fanuc, Siemens
Transport Package
Wooden Pallet
Specification
5000*3200*3200
Trademark
HDCNC
Origin
China
HS Code
8457101000
Production Capacity
500
Product Description
1.machine structure this series machine adopt "T"shaped bed structure,using high rigidity roller linear guideway,the guideway span is large,the overall rigidity of the machine is good,strong bearing capacity,equiped with rotary table,it is suitable for the box,machine base column and other polyhedral parts processing,can acheive one time clamping to complete milling surface,boring,drilling,tapping and other processes of rough and fine processing,to ensure the accuracy of parts requirements,Double worktable can greatly save the clamping time of the workpiece and improve the working efficiency of the machine.2.Machine model
| MODEL | Unit | HMC500APC | HMC630APC | HMC630SAPC | HMC800APC |
| Table size | mm | 500*500 | 630*630 | 630*700 | 800*800 |
| table No. | 2 | 2 | 2 | 2 | |
| table change time | s | 15 | 16 | 20 | 18 |
| Max.load | kg | 500 | 1200 | 950 | 2000 |
| table diving | ° | 1*360/0.001continuous | |||
| No.-W*distane | mm | 5*14*100 | 5*18*125 | 5*18*125 | 5*22*160 |
| rapid speed(x/y/z) | m/min | 48/48/48 | 36/36/36 | 20/20/20 | 36/36/36 |
| XYZcuttingspeed | m/min | 20 | 20 | 10 | 20 |
| spindle center line to table surface | mm | 100-950 | 150-1150 | 0-750 | 150-1420 |
| spindle nose to table center | mm | 100-850 | 100-1000 | 130-1030 | 100-1050 |
| spindle speed | rpm | 6000 | |||
| Max.torque | N.m | 140/191 | 249/307 | 249/307 | 520/619 |
| spindle power | kw | 11/15 | 15/18.5 | 15/18.5 | 18.5/22 |
| Tool holder type | BT50 | ||||
| Pull nail | MAS403 P50T-1 | ||||
| ATC capacity | 40/60 | ||||
| Tool change time(tool to tool) | s | 3.5/4.5 | |||
| Max tool weight | kg | 25 | 18 | 25 | |
| Max. diameter tool | mm | Φ125/Φ250 | |||
| Max. tool length | mm | 400 | 300 | 400 | |
| machine weight | kg | 16000 | 22000 | 16000 | 26000 |
| machine overall size(L*W*H) | cm | 670*420*335 | 760*420*365 | 650*410*345 | 840*500*385 |
3.Standard accessories
| 24 Tool ATC | spindle air curtain dust control system | workpiece cooling system |
| equal division CNC rotary table | Automation lubrication system | Spiral chip removal device |
| chain-plate type chip lifter | full cover | tool,anchor bolt and pad iron |
4.Optional accessories
| 32 arm chain type ATC | 40 arm chain type ATC | ZF gearbox drive |
| central outlet of spindle | spindle oil cooling device | arbitray indexing CNC rotary table |
| scraper lift chip remover | 3 axis linear scale | tool detection device |
| workpiece detection device | door opening protection | portable chip air gun,water gun |
5.Company honors International exhibition
