708m Detection 256X192 15mm Uncooled Thermal Imaging Monocular for Hunting
Basic Info.
Model NO.
CQ-MTC25C15
Type
Monocular
Magnification
10X
Function
Waterproof, Night Vision
Usage
Astronomical, Gift, Bird Watching/Hunting, Travel
Structure
Refractor Telescope
Lens Type
Zoom Lens
Lens
Glass
Objective Aperture
<30mm
Focusing Type
Internal Focusing
Aperture
<50mm
Pixel
256X192
Focal Length
15mm
Detection Range
708m
Paletters
Black Hot, White Hot, Red Hot, Fusion
FFC Mode
Auto, Manual
Transport Package
Export Standard
Trademark
CQ or customized
Origin
Zhejiang
Production Capacity
300 Sets / Month
Product Description
The handheld thermal monocular camera is equipped with a 256 × 192 infrared detector and a 720 × 540 LCOS display. It supports functions of observation, Wi-Fi hot spot, and so on. The high-sensitivity built-in thermal detector provides you with clear view even in total darkness. The monocular is mainly applied to scenarios such as hunting, hiking, law enforcement, searching and rescuing, and etc.
| Model | CQ-MTC25C15 | ||||
| Thermal Module | Image Sensor | Vox Uncooled FPA | |||
| Max. Resolution | 256x192 | ||||
| Pixel Interval | 12um | ||||
| Response Waveband | 8um to 14um | ||||
| NETD | <35 mK(@25ºC), F#=1.0 | ||||
| Focal Length | 15mm | ||||
| FOV | 11.69° x 8.78° (H x V) | ||||
| Aperture | F1.0 | ||||
| Magnification | 1.42 - 11.36 | ||||
| Digital Zoom | 1x, 2x, 4x, 8x | ||||
| Image Display | Frame Frequency | 25Hz | |||
| Monitor | 0.2 inch, LCOS 720x540 | ||||
| Palettes | Black hot, White hot, Red hot, Fusion | ||||
| FFC Mode | Auto, Manual | ||||
| Smart Function | Wi-Fi Hot spot | Yes | |||
| Detection Range | 708m | ||||
| Standby Mode | Yes | ||||
| System | Built-in Memory | 8 GB | |||
| Record Video | Yes | ||||
| Capture Snapshot | Yes | ||||
| Built-in Memory Capacity | 220,000 pictures | ||||
| Power Supply | Battery Type | Lithium battery | |||
| Battery Operating Time | 8 hours with Wi-Fi hot spot off(@25ºC) 6 hours with Wi-Fi hot spot on(@25ºC) | ||||
| Battery Capacity Display | Yes | ||||
| General | Eye Point Distance | 12.5mm | |||
| Work Temp. / Humidity | -20ºC to 55ºC (-4ºF to 131ºF) | ||||
| Power | 5V DC/2A, 1.5W, Type-C interface | ||||
| Protection Level | IP67 | ||||
| Dimension | 158.9x57.7x57mm | ||||
| Weight | <330g | ||||
