Ahf901 Gas Chromatography Analyzer Workstation Data System Gas Chromatograph

Product Description

AHF901 Gas Chromatography analyzer Workstation Data System Gas ChromatographProduct Description
Features:
It can realize full EPC electronic flow control and full computer control of the instrument;Using EPC for pneumatic control, the automation level and overall performance are close to those of international first-tier brands;
High-precision gas flow ensures the accuracy and stability of GC analysis and daily analysis efficiency, and the EPC control accuracy is 0.01psi;Achieves self-protection against gas circuit failures, automatic ignition, and one-button start;
Adopts advanced 10/100M adaptive Ethernet communication interface and built-in IP protocol stack to easily form a local area network to achieve long-distance transmission, remote control, and remote diagnosis;
Equipped with IBrainChrom® workstation, which can support multiple chromatographs (253 units) working at the same time to achieve data processing and reverse control, reaching an industry-leading level;The built-in odbus/TCP server of IBrainChrom ® workstation can easily connect the analysis results to DCS (distributed control system).Product Parameters

Model		901
Sample Introduction System		sample injector and evaporation chamber
Column Oven	Temperature range	RT ~ 450ºC (in 0.1 ºC increment)
	Temperature accuracy	± 0.01ºC
	Cooling time	260ºC to 50ºC in 6 min at 25ºC ambient
	Programmed temperature	0.1ºC~80ºC/min (in 0.1ºC increment)
	Program ramps	16 ramps in total
Flame Ionization Detector(FID)	Detection limit	≤3x10-12g/s (C16)
	Drift	≤1x10-13A/30min
	Noise	≤3x10-14A
	Linearity range	≥107
Thermal Conductivity Detector(TCD)	Sensitivity	≥3000mV, mL/mg (C16)
	Baseline noise	≤20µV
	Drift	≤50µV/h
	Linearity range	≥104
Flame Photometric Detector(FPD)	Detection limit	(S)≤5×10-12g/s (P)≤4×10-13g/s
	Drift	≤2×10-12A/30min
	Baseline noise	≤3×10-13A
	Linearity range	(S)≥103,(P)≥104
Electron Capture Detector (ECD)	Detection limit	≤2x10-12g/s
	Drift	≤0.2mV/60min
	Noise	≤0.02mV
	Linearity range	≤3%
