Multi-Station Vulcanizing Moulding Machine for Rubber Sole

Product Description

Product Description This is a Automatic Platen Vulcanizing Machine for Rubber Sole, with 6 stations sharing one PLC control system,3 motors&pumps, each motor&pump drive 2 stations. Bottom mold plate can move in and out automatically for easy operation.
This 6 stations type vulcanization molding press machine is specially developed for rubber sole production,which improves the productivity greatly.
Compression Molding Press for Rubber Sole is one of our major products among our hydraulic vulcanizingmachine series.
"Geekung" is the famous brand in China for rubber&silicone Rubber Compression Moulding Machine,made with premium components and strict QC management,featuring high quality&reliable operation,durable service life,our rubber compression moulding machine are being sold very popular across China and also were exported to many other counties such as USA,Turkey,India,Mexico,etc,enjoying good reputation among our worldwide customers.
Technical specification:

1.	TYPE	Four columns type, 6 working stations sharing one control panel, each station can be operated separately. Automatic bottom mold plate move-in-out
2.	CLAMPING FORCE	150 TON
3.	MAIN RAM DIAMETER	300mm
4.	STROKE OF MAIN RAM	275mm
5.	DAYLIGHT OPENING	300~350mm
6.	HEATING PLATEN SIZE	450x450mm
7.	MAX. SYSTEM PRESSURE	21 Mpa
8.	WAY OF HEATING	Electric heating
9.	ELECTRIC HEATING POWER	8.8 KW*6
10.	MOTOR POWER	7.5KW*3
11.	TOTAL POWER	75 KW
12.	WORKING DAYLIGHT	01
13.	WAY OF MOLD OPEN	2 RT (top mold is fixed onto the top heating plate,bottom mold fixed onto the bottom heating plate,after opening, bottom mold can move out)
14.	Dimension (m)	L8xW2.2XH2.2
15.	WEIGHT (ton)	18

150T is just a reference model for the Automatic Platen Vulcanizing Machine for Rubber Sole,more sizes&capacity can be customized.
