Module High Voltage Power Supply -12/-6kv 200W

Product Description

Product Description YWB high voltage power supply is a supporting power supply for electrostatic dust removal and air purification and disinfection equipment. It has two working modes: constant voltage and current limiting or constant current and voltage limiting. The output voltage is stable and the current is controllable. It has working, cleaning, and fault status feedback. It has a built-in programmable single-chip microcomputer chip, counter protection, and timed restart. The arc protection sensitivity is adjustable.
*Arc extinguishing function
*Adjustable voltage and current
*Dual closed-loop control
*Reasonable EMC precautions
*RoHS compliant
*UL certified
Typical applications:
Commercial air purifiers, disinfection machines, air conditioning boxes.

Specifications: Input voltage: 220VAC Output high voltage: -12/-6kV Output polarity: Specify positive or negative polarity when ordering Output current: 16mA Output voltage accuracy: 0.5% Signal output: operation, cleaning, fault Protection logic: arc, short circuit, undervoltage, overload protection Operating temperature: -10ºC~+50ºC Storage temperature: -20ºC~+80ºC Humidity: 10%~90% without condensation Weight: about 1.45Kg Optional functions: External voltage regulation Dry contact communication
