4 Axis 6 Axis Automatic Mini Hydraulic Small CNC Press Brake 40t 1200mm for Sale

Product Description

Product Description Features
YSDCNC the new compact DA-58T adds a state-of-the-art complete touch control solution for synchronized press brakes. Offering easiest CNC programming based on the Delem graphical touch screen user interface. This panel based control, standard capable of controlling up to 4 axes, can be integrated in cabinets as well as used in an optional pendulant arm housing. Its 15" wide screen high resolution colour TFT, with industrial grade multi touch technology, gives access to the proven Delem user-interface. It enables direct "hot-key" touch navigation between product programming and actual production. Functions are located where needed, offering optimised ergonomics throughout the entire application. The foundation of every YSDCNC press brake is a solid, mono-block frame made from mill certified, high-yield steel. As a result our press brakes perform accurately and reliably year after year. We're so confident in our frames that we offer a 10-year warranty with our standard machines. Dual hydraulic cylinders located on either side of the ram provide faster approach speeds. The cylinders are synchronized to provide smooth motion resulting in precise ram positions to accuracies of .0004" YSDCNC made press brakes can easily accommodate parts with deep bends and that require long tooling because of our open space
design. Our machines typically have deeper throat depths, larger daylight spaces and longer stroke lengths than any manufacturer
in the market. We've also mounted the RAM GUIDING on the outside of the frame to maximize the distance between the side frames
allowing our brakes to accommodate deep part flanges. Manual and CNC crowning ensures a constant bend angle across the full length of the machine.This is achieved by pre loading the
machine, to offset any possible deflection under load or compensate for any tool wear, so that under load contacting surfaces are
parallel to each other. With CNC crowning systems the press brake control is preprogrammed with machine characteristics and
deflection data. With manual crowning a simple spread sheet or chart can be easily developed for each application. The correct back gauge for the application can have a substantial positive influence on production part volume and accuracy. The more intricate the parts, typically the more axes on the back gaugeyou should have. Volume of parts needs to be considered also. A
smart, experienced brake press operator can bend, form and produce some very intricate parts without even a single axis back gauge. However, the more time it takes to form the correct part, the more costs you have in the part. So the best scenario would
be to have an experienced operator with the correct back gauge system that will magnify their skills. But in today's market,smart,experienced Press Brake operators are getting hard to find. So the correct back gauge for the application will decrease costs per part by helping to make a good press operator, a great one. The less experience an operator is the more axes you should have. Also, experienced operators know the benefit of correct back gauge for applications. YSDCNC is here to consult with you on your application requirements. Its 15" high resolution colour TFT, with industrial grade multi touch screen technology, gives access to the proven Delem use-rinterface. It enables direct navigation between product programming and actual production. Functions are directly located where needed, offering optimised ergonomics throughout the entire application. DA-Offline software maximises machine efficiency and production output of press brakes. The Profile-T software facilitates offline programming and simulation the bending process. Production preparation, makeability and tooling verification, operator training,
adding notes for production and many other functions can be carried out offline.The Profile-T software offers advanced programming in 2D/3D in line with the DA-Touch controller software. The steps from the start of programming to the desired program including its transfer to the control are clearly embedded in the user interface. Programming the product graphically shows a true scale representation of the intended product. Realistic product visualisation gives feedback on feasibility, collisions, required tools and tool adapters for production. Details Images MECHANICAL STRUCTURE The main mechanical structure of the press brake consists of the frame. column,ram,worktable, the main cylinder and backgauge. The main components are through finite element analysis and optimized design by 3D software to fully guarantee the structural strength and rigidity of each component. Laser Protection The DSP laser protection with 3 modes comprehensively protects the personal safety of the operators and maintains the high level of the productivity of the YSDCNC press brake. Special punch and die WILA Hydraulic Clamping System WILA has focused on the R&D of the hydraulic clamping systems and supporting tools of press brake machine for many years, and its quality and service are trustworthy.
Safety Light Curtain The light curtain, YSDCNC chooses is from the well-known brands, with perfect performance to offer a highly effective solution for both operator safety and machine productivity.
Sheet Follower The YSDCNC press brake with sheet follower for bending long and thin sheets. It places on the front of the press brake at the
height of the bending line.
Robotic Arm Press brakes abound, virtually every metal fabrication shop has one or more, but brakes still remain one of the most labor
intensive machine tools in the fabrication process. Every fabricator understands the benefits achieved by running a press brake"lights out" 24/7 at top speeds, which can only be accomplished with automation and robots. Browse our offering of advanced Robotic Bending Automation technology that may be the answer to the efficiency improvements you're looking for.

System control	Delem 53/Delem 58/Delem 66/Delem69/CT8/CT12
Main motor	Siemens motor/servo motor/jiangsu
Electric components	France/Chint
Main hydraulic valve	REXROTH/Germany/jiangsu/zhejiang
Hydraulic pump	SUNNY/USA/jiangsu/zhejiang
Linear encoder	/Italy/jiangsu/zhejiang
Foot switch	KACON/South Korea/jiangsu/zhejiang
Tubing connector	EMB/Germany/jiangsu/zhejiang
Ball screw and linear guide	HIWIN/Taiwan/jiangsu/zhejiang
Servo motor and driver	YASKAWA/Japan/jiangsu/zhejiang
Seal rings	NOK/Japan/jiangsu/zhejiang
Quick clamp	YSDCNC/jiangsu/zhejiang
CNC Punch and die	YSDCNCStandard Punch and 4V die or 2V die

Specification

Model			63T/2500	110T/3200	100T/4000	125T/3200	125T/4000	160T/3200	160T/4000	250T/3200
Bending Length	mm	2500	3200	4000	3200	4000	3200	4000	3200
Bending Capacity	KN	630	1100	1100	1250	1250	1600	1600	2500
Column Distance	mm	2060	2700	3300	2700	3300	2700	3300	2700
Gap	mm	370	400	400	400	400	400	400	400
Daylight Opening	mm	350	400	400	400	400	400	400	400
Stroke	mm	200	200	200	200	200	200	200	200
Table Height	mm	880	880	880	880	880	880	880	880
Table Width	mm	150	200	200	200	200	200	200	200
Fast Approach Speed	mm/s	200	200	200	200	200	200	200	200
Max. Bending Speed	mm/s	10	10	10	10	10	10	10	10
Return Speed	mm/s	160	160	160	160	160	140	140	140
Motor Power	KW	5.5	7.5	7.5	11	11	11	11	15
Length	mm	2825	3500	4500	3500	4500	3500	4500	3500
Width	mm	1650	1650	1650	1650	1650	1650	1650	1730
Height	mm	2430	2540	2540	2540	2540	2580	2580	2580
Weight	kg	5600	8000	950	8500	90000	10000	12000	15000

Our Company
Nanjing Shanduan "YSDCNC"currently has more than 300 employees, including 30 sales engineers and 35 service engineers. The factory covers an area of 26,000 and is equipped with 3 sets floor-standing boring and milling machines, 6 sets gantry planers, 10 sets radial drilling machines, and CNC processing.There are 25 sets centers, with a total of more than 200 sets large and small production equipment.
Our company has passed TUV, SGS, BV, CE and other certifications. Quality assurance, EU approval, the products sell well in more than 100 countries.
Nearly 30 years of expertise in the manufacture of press brakes and guillotines machines give us the security that is needed for future challenges. High standards of quality and a team with the best training and knowledgeare a major condition for our success. Our products are the result of a continued focus on improving internal processes underpinned by high quality levels, that result in the recognition of YSDCNC' S machines as quality garantee equipment.
1.Our wooden case is after fumigation treatment. Needn't timber inspection, saving shipping time.
2. All the spare parts of the machine were covered by the some soft materials mainly using pearl wool.
3.The outmost is wooden case with fixed formwork.
4.The bottom of the wooden case has firm iron jack, convenient to handing and transport. FAQ Is it in stock?
Hello, we have a large amount of stock for standard models, and the regular delivery time is 0~7 days. Customized
models can be completed in 7-30 days (depending on the size and voltage of the machine, the time is different.)
How to buy?
Our company supports a variety of transaction methods, and you can deliver the goods to your door with a deposit
in advance.Various transaction methods such as payment to delivery or delivery to the factory. Consult for details: +8618851629789
How about the after-sales service?
15 minutes quick feedback mechanism. 1-to-1 technical guidance. One year warranty and lifetime service. Free
replacement of non-wearing parts during the warranty period, and lifelong online technical support provided outside
the warranty period. The factory provides spare parts, and the factory installation video provides after-sales service.
How about your quality?
Our company's products are produced according to national standards, and have passed TUV, SGS, BV, CE and other
certifications. Quality assurance, EU approval, the products sell well in more than 100 countries.
What other services do you have?
Free counter, free customs declaration, free installation training for export, free online technical guidance.
