Export Large Quantity 595*595*7/8/9 PVC Laminated Gypsum Ceiling Tile
| US$0.78-1.00 | 4,000 Square Meters (MOQ) |
Basic Info.
Model NO.
595*595*7/8/9
Thickness
7mm
Width
60cm
Surface Treatment
Film Coating
Function
Fireproof Board Ceiling, Soundproof Ceiling, Normal Ceiling, Integrated Ceiling, Heat Insulation Ceiling, Moisture-Proof Ceiling, Mould-Proof Ceiling, Smoke-Proof Ceiling, Waterproof Ceiling
Feature
Artistic Ceilings, Honeycomb Ceilings, Integrated Ceilings, Perforated Ceilings
Certification
ISO9001:2000, ISO9001:2008, CIS, Soncap
Application
Office, Hotel, Household, Dust Free Room, Public
Transport Package
Cartons or Pallets in Container
Specification
1200/*600*600*7/8/9
Trademark
OEM
Origin
China
HS Code
68091900
Production Capacity
10 Million Square Meters
Packaging & Delivery
Package Size
600.00cm * 600.00cm * 70.00cm
Package Gross Weight
15.000kg
Product Description
) Material: PVC laminated gypsum ceiling tile with aluminum foil backing 2) Thickness: 7mm, 7.5mm, 8.0mm, 8.5mm, 9.0mm, 9.5mm, 10mm, 12.0mm, 3) Sizes: 595mmX595mm 600mmX600mm(2'X2') 603mmX603mm 595mmX1195mm 600mmX1200mm(2'X4') 603mmX1210mm 4) Size tolerance: Length <+/-1.0mm, width < +/-1.0mm, thickness <+/-0.5mm 5) Weight: 7.5mm=5kg/sqm, 8.0mm=5.3kg/sqm, 8.5mm=5.8kg/sqm, 9mm=6.2kg/sqm, 9.5mm=6.5kg/sqm 6) Strength: >100N 7) Characters: Non-flammable B1, in accordance with Chinese standard GB8624-1997 8) Installation: Match with ceiling T-bar Packing: Export carton(6PCS, 8PCS or 10 PCS per carton with film)| Specification | Length x Width | 595x595,595x1195,600x600,603x603, 605x605,603x1212,610x1220(2'x4')(mm) |
| Thickness | 7.0,7.5,8.0,8.5,9.0,9.5,12,12.5(mm) | |
| Specification Tolerance | Length:±1.0MM, Width:±1.0MM, Thickness:±0.5MM | |
| Packing | 6/8/10 pieces per carton with shrink wrap bag and importer trade mark printed on the carton strip. | |
| Technical Data | 1..Weight/sqm:7.0MM:5.5KGS,7.5MM:5.7KGS,8.0MM:5.9KGS. 8.5MM:6.2KGS,9.0MM:6.8KGS,9.5MM:7.1KGS,12MM:9.2KGS, 12.5MM: 9.5KGS. | |
| 2.Fire resistant property: No-flammable B1 in accordance with Chinese standard GB8624-1997 | ||
| 3. Length ways & Lateral Ruptures Load:7.0MM>110N , 8.0MM>120N, 9.0MM>140N. | ||
| Installation | Math with Top quality T-32/38 grids with 0.30-0.45MM thickness. | |
| Properties: The top quality pvc laminated gypsum ceiling tile with best aluminum foil backing is of thermal insulation, fire resistant, moisture resistant, no deviation, elegant, economic, environmental and easy installation as the suspend ceiling tile and dry wall partition. Environmental effective resisting dusts conform to the standard of GB6566-2001<>. Moisture resistant, slight deviation ,easy to clean, moisture rate ≤2%,conform to the national standard C/T997-2006 Decorative gypsum board with paper-facing C. Fire resistant A grade, conform to the Item 204 of BG50222-95 of Building material inter decoration design fireproof criterion D. Noise reduction Coefficient :0.1-0.3 E. Thermal conductivity:0.16W/MK. F. Light reflectance:0.75. | ||
