Universal High Precision Tool Grinder Mq6025A 2m9120A
| US$5,000.00-10,000.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
MQ6025A 2M9120A
Type
Surface Grinding Machine
Processing Object
Metel
Abrasives
Grinding Wheel
Controlling Mode
Artificial
Automatic Grade
Manual
Cylindrical Grinder Type
Universal Cylindrical Grinder
Precision
Precision
Certification
CE, RoHS, ISO 9001
Condition
New
Distance Between Centers
700mm
Size of Working Area
940X135
Wheel Head Speed
2800rpm
Mail Power
1.1kw
Weight
940kgs
Transport Package
Plywood Case
Specification
3490kgs
Trademark
HOYONG-TRD
Origin
Shandong, China
HS Code
8460190000
Production Capacity
10 PCS/Month
Product Description
SHARPENING TOOLS MACHINE FEATURES:This series machine are specially suitable for sharpening tools in HSS, tungsten carbide and other materials, also for cylindrical, surface, slot and profile grinding work.
By using additionl attachments, you greatly extend the range of application of there machinery and can solve individual machining problems, such as grinding for various hobs, tools, sharpening cutters, twist drills and steep taper reamers, etc. The series machine wheelhead with two-dimensional setting(except MA6025B), workhead stock swivels with double dir. And supplied with ISO-50 taper hole. Worktable is supported in preloaded ball guide and can be driven by hand or by infinitely changing rate hydraulic.
SPECIFICATIONS:
| PARAMETERS | MQ-6025A | |
| Swing dia.of workpiece | 250mm | |
| Distance between centers | 700mm | |
| Area if tge ioeratuib tavke | 940*135mm | |
| Longitudinal travel of table | 480mm | |
| Swing angle of table | 120°(60°) | |
| Max travel of wheel head cross vertical | 225mm | |
| Wheel center line of the min distance between the top | 50mm | |
| Wheel center line of the max distance between the top | 265mm | |
| The max movement in the vertical direction | 270mm | |
| Wheel center line up to the top | 200mm | |
| Wheel center line down to the top | 65mm | |
| Swing angle of wheel head in horizontal pline | 360° | |
| Swing angle of wheel head in vertical pline | 30°(±15°) | |
| The end taper of the spindle | MT3# TAPER ANGLE | |
| Grinding head motor power 50Hz | Power | 0.85/1.1KW |
| Speed | 1400/2800rpm | |
| The speed of grinding head | 3010/6010rpm | |
| The Motor of Cylindrical grinding attachment:50Hz | Power | 0.25KW |
| Speed | 1400RPM | |
| The size of the machine | 1650*1150*1500mm | |
| The weight of the machine | 940kg | |
