Solar Inverters off Hybrid Grid Inverter

Product Description

Outdoor portable energy storage power supply


FEATURES:
1.DSP digital control technology, providing stable, reliable and pure sine power supply.
2.DSP core chip and open design architecture, highly costomizable, fit for automation and intelligent monitoring system, supporting SNMP, Ethernet, support mobile APP monitoring, web page monitoring, and PC remote centralized monitoring.
3.High-efficient bypass direct supply offline power supply, detecting mains power automatically. When the mains power is stable, it supply by bypass, when the mains power is out of tolerance, it comes to regulation mode simultaneously, assuring the reliable power supply for loads.
4.Built-in LiP04 battery, providing 5-10 times backup time the same volume of lead acid battery, especially suitable for narrow space and long-term power needs.
5.Specified lithium battery charger and BMS
4-state charging: constant current, constant voltage, floating charge, shutdown, triple circuit over-voltage protection, preset over-temperature, over-pressure switch interface. Battery pack and controlling logic is highly customizable.
6.Wide working temperature range
Working temperature:-10~50oC , allowing full play to the advantages of lithium battery.
7.Wide input voltage and frequency range
Voltage range: 90V~300V, frequency range: 40~70Hz,durable in terrible power environment, reducing battery discharge and prolonging the battery service life.
8.Excellent load adaptability
Adaptive for 50Hz/60Hz, output 200/208/220/230/240Vac, compatible with various loads.
9.Working with generator
The wide input voltage and frequency range can effectively isolate the bad power generated by the generator and provide pure, safe and stable power supply for the loads.
10.High output power factor
Using active power factor correction technology (PFC), the input power factor is above 0.99, effectively avoiding grid pollution and reducing electricity bills.
11.Reliable product design
Glass fiber double-sided circuit material, with large span components, strong, corrosion-resistant, greatly improving environmental adaptability.
12.Dust-proof design
Reasonable air duct design and three anti-paint coating can effectively prevent the accumulation of dust and pollutants from corroding the circuit.



Specifications
