Three Axies 250CNC High-Performance Surface Grinding Machine Tool for Experts

Product Description

250/2550CNC Surface Grinding MachineThree Axies 250CNC Multifunction Grinding Machine Tool
Adhering to our steadfast commitment to excellence and innovation, we at Cheng Yu Machinery technology continuously enhance our product line. We hold the right to amend any specifications, mechanics, or designs at any given time, without prior notice or obligation, ensuring state-of-the-art offerings.

	parameter	unit	CNC-250	CNC-2550
general picture	Table size (x*y)	mm	200×500	250*500
	X axis travel	mm	580	580
	Y axis travel	mm	230	280
	Max center of wheel to table	mm	380	380
	Maximum load	kg	200	200
Table	Table T cell specification	mm×N	14×1	14×1
	Table speed	m/min	0-25	0-25
Y axis	Minimum feed	mm	0.001	0.001
	Single feed		0.1~10	0.1~10
	Fast moving speed	mm/min	0~1200	0~1200
Z axis	Minimum feed	mm	0.001/0.01	0.001/0.01
	Fast moving speed	mm/min	0~800	0~800
grinding	grinding wheel size max	mm	Φ200×Φ31.75×19
	grinding wheel speed	R.P.M	0~3600	0~3600
motor	spindle motor	HXP	2×2	2×2
	the Z axis motor	W	750	750
	the Y axis motor	W	750	750
	the X axis motor	W	1500	1500
	cooling motor	W	90	90
Size	height of machine	mm	2000	2000
	floor space	mm	2000×1350	2000×1450
	weight(about)	kg	1450	1550

Established in Dongguan City, Guangdong Province, Cheng Yu Machinery Technology Co., Ltd. boasts a heritage of 30 years of expertise in grinding machine manufacturing, stemming from Taiwan. Our company is a proud ensemble of seasoned professionals dedicated to delivering technological brilliance. As CNC machine tools evolve rapidly, they embrace a future characterized by high-speed, precision, and composite capabilities. The direction is clear: intelligent design, open systems, parallel drives, networking solutions, and environmentally conscious initiatives are key trends shaping the future of CNC machine tools. Dongguan Chengyu Machinery Technology Co., Ltd. takes pride in its specialization in the production and processing of premium machine tools and accessories. We are guided by our business principles of 'technology, innovation, and reliability,' and a quality policy that emphasizes meticulous attention to detail. Our mission is to provide top-tier products and services tailored to the unique process, technology, production requirements, and quality expectations of our clients. By leveraging advanced design and production technology, we continuously enhance product applicability, expand the numerical control industry's potential, and achieve superior automation, precision, and quality. We operate with a complete scientific quality management system, first-rate equipment, and unrivaled expertise. In response to the burgeoning market demand, Chengyu Machinery excels in crafting high-precision CNC surface grinding machines, CNC forming machines, four-axis punch grinders, vertical slider grinders, and gantry rail grinders. We also design and manufacture industrial robots, automated production lines, and comprehensive integrated applications. Below is a brief overview of our CNC grinding machine series: I. HS series 618 / 250 / 3060 / 4080 / 40100 (available in servo and hydraulic types) Processing Capacity: Ideal for surface grinding and precision grooving. Patented Hydraulic Control System: Uniquely designed for hydraulic types, ensuring unmatched control. Functionality: Equipped with advanced grinding programs including flat surface and groove cutting. Feed Mode: Customizable options for front, back, left, and right. Each program remembers its specific feed mode for seamless operation. Automatic Shutdown: Built-in safety feature triggers automatic shutdown to prevent grinding wheel overload. II. (available in servo and hydraulic types) Processing Capacity: Handles surface grinding, intricate grooving, and complex scheduling with ease. Patented Hydraulic Control System: Specialized for hydraulic models, offering superior precision. Functionality: Comes with a suite of grinding programs for surface, groove, sole, side grinding, and more, including unequal distance and depth variation. Grinding Wheel Dressing: Innovative bottom plane dressing facilitates automatic dressing and compensation during grinding cycles, based on predefined rough and fine grinding settings. Feed Mode: Fully adjustable with memory retention for each program, supporting front, back, left, and right directions. Equidistant and Non-equidistant Grooving: Achieve precise results with customizable spacing. 3. Four-axis CNC Grinding Machines: Available in both horizontal and vertical configurations. Processing Types: Versatile operations including arbitrary equal division and skipping tooth processing. Waist Circle: Customize with AB size input for precision. Triangle Fillet: Enter inscribed circle size B and fillet size R for exact specifications. Quadrilateral Fillet: Define side lengths A and B, along with fillet size R, for tailored results. Eccentric Circle: Input eccentricity and define starting and ending diameters for precise machining. Circle: Effortlessly input the starting and ending diameters to achieve precise and flawless circular dimensions. Arc: Simply enter the arc size and rotation angle to craft exquisite and perfect arcs with ease. Unlock the full potential of your machining with the Step Difference, Rotation Profile, and more, allowing you to achieve unparalleled precision and quality. Convenience at your fingertips, with the ability to save your processing schedule as a processing file. Effortlessly recall it for future use, ensuring seamless and efficient operations.
