Tph1610 High Speed CNC Drilling Machine for Plates

Product Description

TPH1610 High Speed CNC Drilling Machine for Plates
Applicable Industry:

Special CNC machine for punching, drilling and marking of steel plates in the field of steel tower industry. It is also used to punch and mark of steel plates of other industries.
Main Component:
The steel cutting production line mainly includes the following units: cutting unit, transverse feeding platform, feeding conveyor roller bed, CNC feeding carriage and carriage track, unloading conveyor, and transverse unloading platform.
Product Parameters

Model		TPH1610
Max size of work piece L×W(mm)		1600×1000
Marking unit (Optional)	Marking Force (kN)	80
	Character Size(mm)	14x10
	Qty. of Characters	40
Drilling Spindle	Qty.	1
	Taper Hole of Spindle	BT50
	Max. Drill Diameter (mm)	Φ40
	Drill Thickness(mm)	≤40
	Spindle Speed(r/min)	30-3000
	Motor power of Spindle (kW)	22
	Spindle Feeding Stroke(mm)	300
	Distance between Spindle Tip to Work Table(mm)	100~400
Min. Distance between Hole and Plate Edge (mm)		25
Quantity of CNC axis		4
Qty. of Hydraulic Clamps		2
Vertical Pressing Quantity of Drilling Hole		1
Programming Mode		Auto CAD or lofting software
Total Power (kW)		About 35
Overall Dimensions(L*W*H)		About 3500*3400*2800
Net Weight of Machine(kg)		About 8200

Detailed Photos
After Sales Service
Installation:
The seller shall send one engineer to the buyer's country for installation, commissioning and training. The buyer is responsible to provide all necessary equipments for handling and lifting the machine parts before seller's engineers go to the buyer's plant. In addition, the buyer should provide workers to support in installation activities, under supervision from the seller's engineers.

Commission:
The Supplier should give drawings and other details of material/preparation required for installation of machinery which the buyer has to prepare and keep ready before the machine arrives at the buyer's factory. Installation and commissioning can be finished within 5-10 days for above machine generally.

Training:
Training will include training on computer programming, machine operation and troubleshooting. The training time is at most 5 days for this machine.
The buyer should arrange no less than two people for accepting training. After training, the buyer should sign the "Receiving & Inspection Report" supplied by the seller to demonstrate the successful finish of commissioning and acceptance of the buyer.

Company Profile
Factory:
With the development of SUNRISE, now our company has occupied important position in this industry. Due to the orders and sales performance is continuously improving, in order to better development, to meet customer's demand, and to provide customers high-quality equipment with the shortest time, our company have bought the new site, the area about 50,000 square meters, this will make sufficient preparation for development of our company and every customer.

Workshop:
Quality make brand, honesty win market, harmony converge talents, and innovation promote development. Our ability to consistently provide innovative, high quality products that outlast and outperform the competition, is why we are the one of the most successful companies offering the most advanced and productive solutions in the CNC machine industry.

Warehouse:
Manufacturing customer oriented products has always been our supreme concern. We believe that quality is the soul of an enterprise forever. Therefore, we never compromised with the quality of our products. We adopt advanced, scientific modern management ideas and system to realize supervisory control among all aspects of produce, inspection, sale and service etc., which help control quality, increase work efficiency and guarantee products' stability, reliability and precision. Therefore, the enterprise can achieve rapid and sustainable development.

Team:
We are a team of experienced and dynamic professionals who are experts in handling precision work through scientific processes. The professional excellent talents unite a powerful and creative team of design, research and development, which build our solid technical strength and competitiveness. And our company is developing fast and supply specialized service to all customers.
Packaging & Shipping
1. Special logistics packaging
2. Suitable carton size
3. Fasten
4. Professional placement
5. Professional shock
6. Complete package
Certifications
SUNRISE is focus on quality and company's image. We win market with good quality and service. The company has already passed International Quality Management System ISO9001:2008 certification for many years and also got the CE certificate, smoothly got the title of High and New Tech Enterprises. And has more than ten own intellectual property rights and patent technology. We have own import and export right. Our products exported to Russia, South Asia, South east Asia, Middle East, South America, Africa, Australia, Eastern Europe etc.
Customer Photo
SUNRISE CNC MACHINE ALL OVER THE WORLD, HAVE EXPORTED MORE THAN 30 COUNTRIES. Our products exported to Russia, Ukraine, Albania, Romania, Iran, Israel, Jordan, Turkey, Uzbekistan, Egypt, UAE, Saudi Arabia, Lebanon, Mexico, Argentina, Brazil, Morocco, South Africa, Kenya, India, Australia, Indonesia, Vietnam, Sri Lanka, Singapore, Malaysia, Thailand, Myanmar etc.
FAQ
Q: Are you trading company or manufacturer ?
A: We are factory.

Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is 30-50 days if the goods are not in stock.

Q: What is your terms of payment ?
A: Payment 30% T/T in advance, 70%balance before shippment.
