Knife Grinding and Polishing Machine

Product Description

INNOVO-KE Knife Grinding and Polishing Machine

INNOVO-KE Knife Grinding and Polishing machine is the INNOVO company under INNOVO-E Series sharpener works, from the development of automatic control system with a new generation of PLC products, is a set of grinding and polishing (to knife flowers) in one of the new dual-Grinding Grinding. It's especially for small and medium sized books and printing.
INNOVO-KE Knife Grinding and Polishing machine sharpening grinding a stepping motor, PLC control system programming; can automatically adjust the coarse grinding, grinding times, high precision grinding; wheel auto-feed, can be memory, storage, can be Dynamic tracking, convenient operation, high degree of automation in the same sharpener in the highest degree of automation, greatly improving efficiency.
Structural characteristics of equipment:

STRUCTURAL CHARACTERISTICS OF EQUIPMENT

Water-cooled motor grinding wheel head

Polishing grinding head:German East Y series three-phase asynchronous motor

Polishing grinding head:German East Y series three-phase asynchronous motor

Wheel, wool wheel manual feed

Fixed grinding head travel

Mobile grinding trip: travel speed: 6 m / min Grinding speed :0-1400 r/min

Rack and pinion

Cantilevered fuselage structure

Magnetic chuck tool holder table

Worm drive tool holder

Table rotation angle: 0-±90°

FUNCTION OF CONFIGURATION

Imported electrical components (optional device)

Scraper jig (optional device)

Main technical parameters:

Formation grinding:	Face grinding, automatic reciprocating
Operating angle turret:	0-±90 °
Grinding wheel speed:	1400 r/min
Wheel Type:	Wheel Type:
Wheel Specifications:	Cup Φ200xΦ100x100 mm
Reciprocating speed:	6 m/min
Reciprocating speed of polishing:	8 m/min
Grinding motor:	Y90L-4P 1.5 KW
Polishing motor :	YS6314 0.55 KW
Reciprocating motor :	YS7124-W 0.55 KW
Cooling water pump :	JCB-22 0.125KW
Polishing wheel :	Φ120×Φ18×12 mm

And Comparison of different Specifications

No	Specifications / Model	Maximum grinding length	Overall dimensions	Weight
	INNOVO-KE	mm	mm	Kg
1	1700E	1730	3740x1050x1500	2200
2	2200E	2230	4340x1000x1330	2500

Machine transport and packing
__________________________________________________________________________
1. The packing of small machines is confirm to export wooden case standard, strong and durable. The wooden case's thickness is generally 1 cm.
2. In order to be waterproof, we usually use bubble film to wrap machine.
3. We can handle shipping for customers too.
