PP Filler Masterbatch Compounding Machine Recycling Machine Granulation Production Line

Product Description

Product Description
JWELL High output efficient 630mm to 1600mm plastic shredding recycling big diameter PP HDPE PE PVC huge pipes crusher Large Pipe Horizontal Shredder Machine DYSSG shredder is able to shred the PE,PP,PVC pipe with dia.1200mm,the length 3-6m pipe can be shredded directly without cutting,and the rotary speed is slow and stable.
DYSSG shredder has the main advantage of energy saving safe and effcient,and the system is controlled by PLC center control system. Product Description
Environment Condition:

Location: Indoors

Power Supply: Safe Area

Humidity Degree: ≤85%

Temperature: 0-35ºC

Work Condition:

Supply Voltage: 3*415V+N+PE, 50HZ

Voltage tolerance: +10%, -10%

Control Voltage: 24V DC/ 240V AC

JWSSG shredder has the main advantage of energy saving and high efficiency, the large diameter pipe can be shredded directly without cutting, and the rotary speed is slow and stable. The pipes are put into the flat feeding tank, and the tanks will close automatically, and push the pipe by hydraulic into the center axis for shredding. The material after shredding is transported by conveyor belt for secondary crushing. After that, you will get the requested flakes. And the system is controlled by PLC center control system.
Product Parameters

Max Shredable pipe (mm)	Mechanical Pusher Power (kw)	Output (kg/h)
630	11	800-1000
800	11	1000-1200
1000	15	1200-1500
1200	15	1500-2000

Model	Feed Dia (mm)	Rotor blade Swing Diameter (mm)	Rotor Speed (rpm)	Drive Power (kw)
DYSSG-630	750*790	848mm	39	2*30
DYSSG-800	950*960mm	1028mm	33	2*37
DYSSG-1000	1140*1160	1258mm	27	2*45
DYSSG-1200	1340*1360	1478mm	23	2*55

Application

Our Advantages
Pioneering Efforts, Unity and Struggle
Seeking for innovative and practical technology, We grow rapidly with the market trend. Every person is a product
Person in creating better customer experience. Trust is the corner stone of our corporate. As we truly believe the
Staffs are the most precious wealth, if we take care of our employees, so as each person would take care of the
Customers. "Be Honest" is the core idea for us to build an everlasting enterprise.
Consistent quality, Brands Building.
We have kept an eye on the quality during all procedures since the birth or our enterprise. Consistent quality would
Be the only virtue which we highly uphold. Every product marking JWELL represents safety, stability, reliability.
Cutting edge technology, Added value products
We have professional designing engineer who recognize the market need well. We add value to customers' business
By innovative designs and products that will provide competitive advantage over your rivals.
Capable of ultimate one stop global extrusion solution
There are various of products ranges, flexible order quantity, customized designs. Our products are capable of ultimate
One stop solution for different sizes of projects and business. With pre-sale and after-sale assistance, prompt delivery,
We care the customers' satisfaction and benefits.
Company Profile
FAQ
FAQ PART ONE:
RFQ1: How many electric, water, air need for the machines?
Jwell : We supply the whole layout for the extrusion project including workshop details.
RFQ2: Can I operate machine if don't have experienced engineers?
Jwell:we can send enough engineers to customer's factory in short-time (5-15days), and also customer can send engineer to JWELL factory for training to get skills of machine operation and maintaining.
RFQ3:Can we do quality checking and test running before shipment?
Jwell: 100% confirm, run and test machines before shipment with quality assurance.
RFQ4: Is it safe to use JWELL machine?
JWELL: Yes, JWELL company apply ISO and 6S production management, we carry out CE, UL quality and safety international standards.
RFQ5: How can we get spare part?
JWELL:we adopt International Brand that customer can find it in everywhere, such as Siemens, Sneider, Omron, Delixi etc, or send parts by DHL, Fedex, TNT express or by air.
FAQ PART TWO:
Q1. Is Jwell Machinery a Manufacturer?
A1: Yes, all key components of the extrusion line are made by JWELL.
We own 8 manufacturing bases and sales center in Shanghai, Haining ,Suzhou, Changzhou, Zhou Shan, Chuzhou, Foshan,Quanjiao China.
Jwell made the first Chinese screw and barrel in 1978 in brand name Jinhailuo. After more than 40 years development,
JWELL is one of the biggest extrusion machine supplier in China with 300design&test engineer, 3000 employees.
Jwell has become the premier supplier of extrusion lines and reliable business partners. Welcome to drop in us.
Q2: How many brands does Jwell Machinery own?
JWELL: Jwell Machinery owns more than 20 subsidiaries, China famous brand JINHAILUO, JWELL, BKWELL, DYUN
Are our Trade Marks.
Q3: If we don't find what we need from your website, What should we do? Do you make extrusion lines as per
Customers' specific requirement?
JWELL: Yes, we can provide bespoke service to customers with specific requirements. You can send the detailed
Requirements by email. We will check if we can develop them. We develop new machinery every month, and
Some of them may not yet be updated on our website.
Q4: How do you ensure your machinery and service quality?
JWELL: Our machines taking the European standards and follow the Germany type of business, we cooperation with
International famous brands Siemens Sneider Flender Omron ABB WEG Falk FUJI etc. Our company continuously
Imports over 1000 international first-class high precision processing equipment such as multistage machining centers,
CNC lathes and CNC milling machines from Korea, Japan etc. All our processes strictly adhere to CE certification,
IS09001 and 2008 quality management system. And we have 12 months quality warranty time. We testing the
Machine performances before each delivery. Jwell service engineers will always be here for anything you needed.
Q5: How can I order and make payments?
JWELL: Once clear your requirements and determined extrusion line is ideal for you. We will send technical solutions and
Proforma Invoice to you. You can pay via TT bank transfer, LC as you like.
Q6: If we find your bank account or email different as before, how should we respond?
JWELL: Please don't send the payment and double check with us before arrange payment (Bank details will be listed in
Every piece of proforma invoice. ) " ".
Q7: How long is the delivery date?
JWELL: Usually it takes about 1 - 4 months depends on different machinery upon receipt of order advance payment.
Q8: What is your Minimum Order Quantity?
JWELL: One. We provide both customized extrusion lines and technical solutions. Welcome contact with us for technical
Innovation or improvements for your future purchasing plan.
Q9: What is your production capacity?
JWELL: We produce more than 2000 advanced extrusion lines every year world wide.
A10: What about shipping?
JWELL: We can send the small spare parts by air express for urgent matter. And the complete production line by sea
To save the cost. You can either use your own assigned shipping agent or our cooperative forwarder. The nearest
Port is China Shanghai, Ningbo port, which is convenient for maritime transportation...
Q11: Is there any pre-after sale service?
JWELL: Yes, we support our business partners by pre-after sale service. Jwell has more than 300 technical testing
Engineers traveling world wide. Any cases would be responded with prompt solutions. We provide training, testing,
Operation and maintenance service for a life time.
Q12: Are our business& money safe with Jwell Machinery?
JWELL: Yes, your business is safe and your money is safe. If you check China company blacklist, you will see that it is
Not contain our name as we never crook our customer before.
