Air Solar Manifold with Both Sides Open Evacuated Tube for Drying Food, Fruit, Vegetable
| US$469.00-639.00 | 10 Pieces (MOQ) |
Basic Info.
Model NO.
20 tubes
Certification
API, ISO, CB, CE
Concentrating
Yes
Working Temperature Range
Medium Temperature
Type
Vacuum Solar Collector
Application
Water Heater, Solar Thermal, Air Conditioning System
Pipe Material
Glass
Transport Package
Carton, Wooden Box
Specification
20 tubes
Trademark
MLSUN
Origin
China
Production Capacity
300000 Sets/Year
Packaging & Delivery
Package Size
250.00cm * 190.00cm * 20.00cm
Package Gross Weight
65.000kg
Product Description
We developed Hot Air solar collectors with Two-Ends-Open evacuated tubes.Two-Ends-Open evacuated tube is double vaccum all glass tube, cold air blowed into at one end, heated by solar energy, hot air blowed out at the other end.
Data sheet of Hot Air solar collector (with Two-Ends-Open evacuated tube).
| Model | AIR-20 | AIR-30 |
| Dimensions | 1600*1867*160 mm | 2400*1867*160 mm |
| Aperature area | 3 m2 | 4.5 m2 |
| Air flow | 15 m3/h | 20 m3/h |
| Weight | 45 kg | 65 kg |
| Both sides open tube | Φ58*1800 mm | Φ58*1800 mm |
| Tube quantity | Two-Ends-Open vacuum tube, 20 tubes | Two-Ends-Open vacuum tube, 30 tubes |
| Tube material | High borosilicate glass 3.3 | High borosilicate glass 3.3 |
| Frame material | Galvanized steel | Galvanized steel |
| Insulation | Polyurethane 30mm | Polyurethane 30mm |
| Hail resistance | 25 mm | 25 mm |
| Working fluid | Air, water | Air, water |
| Application | Air heating, room heating, desalination, drying, hot water | Air heating, room heating, desalination, drying, hot water |
