Agriculture Harvester China 88HP Rice Combine Harvester 4lzt-4.0zd with Attachments
Basic Info.
Model NO.
4LZT-4.0ZD
Application
Cotton, Rice, Corn, Fruit, Wheat, Soybean, Tubers, Straw
Power Source
Diesel
Harvest method
Cutting
Drive Type
Gear Drive
Transmission
Soft Shaft
Portable Harvester Type
Backpack Type
Certification
QS, GMP, ISO9001:2008, CE
Color
Green
Condition
New
Application Field
Agriculture, Livestock, Aquaculture, Forestry
Warranty
1 Years
Cutting Width
2m
Cleaning Sieve
1.76m2
Feeding Capacity
4kg/S
Efficiency
1.2-1.5acre/H
Engine Power
88HP
Fuel Tank
160L
Grain Tank Capacity
1.4m3
Min. Ground Clearance
325mm
Weight
3260kg
Transport Package
Nude
Specification
5270*2500*2960mm
Trademark
Top Brand
Origin
China
HS Code
8701901190
Production Capacity
50
Product Description
Products Description
Agriculture Machine 4LZT-4.0ZD Crawler Wheat Combine Harvester
* Upgraded and optimized travelling system brings better trafficability in paddy field and higher efficiency.
* Chasis with higher ground clearance with min.clearance of 315mm, better trafficability in paddy field and higher efficiency
* Upgraded and optimized header conveying system, strong ability of handling crops, systematically solve the problem of troubled
feeding in longitudinal axis flow model
* New driveline system with reinforced and more reliable material
* 2SB belt is used as the conveying belt in conveying sink, with higher conveying efficiency and longer service life;imported
bearings are used in key parts with better reliability
* Screen widened to 1080mm, with 15% larger screening area, ensure perfect cleaning and very low impurity.
Product Paramenters
| Model | Unit | 4LZT-4.0ZD |
| Dimension (L×W×H) | mm | 5270*2500*2960mm |
| Threshing drum(length*φ) | / | 2000mm×φ620 |
| Cutting width | m | 2 |
| Cleaning sieve | | 1.76 |
| Feeding capacity | kg/s | 4 |
| Efficiency | acre/h | 1.2~1.5 |
| Engine power | hp | 88 |
| Rubber track | mm | 500mm width*90mm pitch*53 section high stripe track |
| Fuel tank | L | 160 |
| Grain tank capacity | m³ | 1.4 |
| Transmission | / | Mechanical+HST(Hyro-Static Transmission) |
| Min. ground clearance | mm | 325 |
| Unloading Height | | 4m 270° rotary |
| Weight | kg | 3260 |
| Harvesting Crops | / | Rice, Wheat, Corn, Soybeans, rapes |
| ROPS or Cabin | / | Safety shelf, optional drivier's cab |
Product Pictures
