High Quality Solid State Disk PCBA PCB Assembly Service Wireless DIY Module for Teaching Equipment

Product Description

Support Customized Development And Production Of Wireless Intelligent Module Pcba/App/Md.
Do You Plan To Customize The Design Products?
Talk To The Chief Design Tam About Your Product Ideas!
Think about your ideas with a "pens": conceptualize and innovate design concepts and obsessions from the tip of a pen and make prototypes for project owners.
" PENSVOX" specializes in project product prototyping for crowdfunding project owners, innovative tech startups and new technology companies.
Discover for them how to make, discuss, improve and build ideas.
Q:Regarding the app that connects to the smart ring, it complies with GDPR and CCPA.
Q: Regarding the application connected to the smart ring, it complies with GDPR and CCPA.
A: No registration on the app, you can directly log in to the connected device, and the stored information is
A: No need to register on the app, you can directly log in to the connected device, and the stored information is
Product Parameters

Product Name	Wireless Control Module	Function	Wireless Smart APP Control
Power supply	Customized 3.7-12V	Application	Android IOS
MOQ	100pcs	Transmission rate	1000Kbps
Chip	JL	Working mode	wireless bluetooth

Chapter 2 Basic Function List
1. Chip: MT2503/MTK3333/MTK5931
2. Memory: 32M Flash Memory
3. RF power amplifier: RDA6625E
4. Main board stacking size: 20x35x5mm
5. Working environment temperature: -20 ºC -+70 ºC
6. Working environment humidity: 20% -80 MRH
7.SIM card: nano sim k, compatible with side insertion and flip (default)
8.GSM frequency band: 850MHz/900MHz/1800 MHz/1900MHz
9.GPRS: Class 12
10 batteries: 3.7V/3.8V2000mAh
11. Average standby current: less than 2ma (depending on the connection method)
12. Sensors: 3D G-Sensor (PhD 250/253)
13.GPS Beidou accuracy: within 10 meters
14.WIFI positioning accuracy: within 50 meters
15.GSM positioning accuracy: 50-200 meters (depending on network conditions)
16. Speed accuracy: 0.1 meters/second
17.GPS positioning time: Cold start -38s (Open sky) Hot start -2s (Open sky) Different due to environmental impact
18.GSM antenna: PIFA antenna
19. standby time: determined by battery capacity and connection method
20. working voltage "3.5-4.2V (automatic shutdown at 3.4V low power)
21. Charging current: Charging 5V-600mA miro
22.GPS antenna: high-performance 15X15x2mm ceramic antenna
23. developer testing: locate once every 1 second, report gsm socket every 4 seconds
24.TF memory card: maximum 32GB c12
25. Bluetooth: Bluetooth 3.1
26. Horn: 2W 0916
27. Motor: Motor 2.8V 600ma
28. button "On/Off" button, 2 external GPIOs, reset
29. Short circuit switch: power-on function
30.LED tricolor light: satellite signal light, sim signal light, power signal light
31.USB: Expansion port x1. Comes with microx1
32. serial port: TTL TX RX GND
About Us
PCBA Assembly Capability (1) 7 high-speed SMT precision equipment
(2) 1 DIP through hole welding production line
(3) 2 assembly test production lines
(4) 1 product packaging line
(5) All assemblies are ROHS compliant
PCBA Assembly Service (1) PCBA prototype assembly
(2) PCBA batch assembly
(3) SMD surface mount technology
(4) DIP jack welding assembly
(5) BGA ball array assembly
Our Service Our Service Capability and Services Range: 1.PCB circuit layout and production
2.Plastic and metal casing design services
3.Product customized packaging design
4.SMT/SMD parts assembly and DIP through hole soldering(PCBA)
5.IC programming software(pre-programmed), PCBA functional testing and verification
6.Complete product assembly(including plastic,metal casing,PCBA motherboard,cables, swithes and other components, etc.
7.ROHS environmentally protection material supply
8.Logistics arrangements, importing and exporting goods from China
PCB Fabrication

NO.	Item	Specification
PCB Manufacturing Capabilities
1	PCB layers	1 to 32 layers
2	PCB board material type	FR4,High-TG FR4,CEM-1,ALU,CEM-3,Rogers,HDI,etc.
3	Max dimension	600 x 1200mm
4	Min line width	0.1mm
5	Min spacing	0.1mm
6	Dimension tolerance	±0.1mm
7	Min hole diameter	0.2mm
8	Pcb board thickness coverage	0.2 to 6.0mm
9	Min copper thickness in hole	0.02mm
10	DK thickness	0.08 to 6.0mm
11	NPTH size tolerance	±0.025mm
12	PTH size tolerance	±0.025mm
13	Dimension tolerance	±0.1mm
14	Hole position tolerance	0.075mm
15	Laser drill hole size	0.1mm
16	Min soler mask	0.01mm
17	Minimum size of solder mask separation ring	0.05mm
18	Max board twist and wrap	≤1%
19	Finished hole diameter	0.2 to 6.0mm
20	Flame resistance	94V-0
21	Impedance control tolerance	±5%
22	Outer layer copper thickness	8.75 to 175um
23	Inner layer copper thickness	17.5 to 175um
24	Solder mask type	Blue,Green,Black,Yellow,Red,White
25	Surface finish	HASL,OSP, ENIG, Gold plating,Immersion Tin,etc.

Application Market
Visit us
Certifications

Packaging & Shipping
FAQ
Q1, who are we? Why choose us?
A1: We are an electronics manufacturing services (EMS) supplier, we provide customers with flexible and reliable electronic manufacturing solutions, from parts procurement, (board) PCBA processing, DIP through-hole soldering, PCBA testing, cabinet assembly and One-stop electronic manufacturing services such as product testing, packaging, and logistics.
A2: With a variety of different product introduction experience, we have established a team of perfect ISO9001 quality system certification, including: human resources, marketing department, project management, engineering technology, PMC procurement, quality management, production, warehouse management And many other departments.
Q2, what information do we need to provide in order to get an accurate quote quickly?
A: The more detailed the product data and requirements are, the faster and more accurate the quotation will be, such as:
1.PCB manufacturing: Gerber files or PCB files
2.PCBA manufacturing: Gerber files, BOM bill of materials.
3.PCB requirements for sheet metal, thickness, copper thickness, tin spray, immersion gold, silk screen color, sheet color and other documents.
4.Comprehensive and detailed BOM bill of materials, including: part number, usage, specific specifications, parts manufacturers.
5.Replaceable parts, confirm approved spare parts.
6.PCBA IC pre-programming, providing software burning test version, test method.
7.PCBA or product assembly requirements, providing specific executable files.
8.If plastic, metal, cable, packaging, etc. are required, a document drawing that can be produced is required.
9.For other special requirements, a schematic document is required.
Q3, what is the minimum requirement for the order?
A: We support customers to arrange the order quantity according to their own needs. There is no minimum quantity limit. Of course, the more orders, the more competitive the price competition.
Q4, How long is your order production time?
A: According to the complexity and simplicity of the product, when the parts are ready, we need 3-10 working days to prepare all the components.
Q5, can we visit your factory?
A: Our production facilities are always welcomed by customers. Please call us at +086-0755-32937225
