US$7,950.00-19,500.00
|
1 Piece
(MOQ)
|
Basic Info.
Model NO.
PSB450/600/800/1000/1250
Object
Juice Oil Chemical Industry
Separation Mode
Filter Type
Operating Type
Continuous Type
Centrifuge Type
Top Discharge Centrifuge
Extraction Tower Type
Turntable Tower
Raw Material
304/316L Food Grade
Application
Active Pharmaceutical Ingredients Centrifuge
Transport Package
Standard with Wooden Pallet and Poly Film Wrappin
Specification
1*0.75*0.78
Production Capacity
200 Sets/Month
Product Description
Product Introduction
Product Parameters
Model | 450 | 600 | 800 | 1000 | 1250 |
mm drum diameter | 450 | 600 | 800 | 1000 | 1250 |
rpm Rotational speed | 2000/2500 | 1500/2000 | 1500/1750 | 1080/1200 | 950 |
L drum volume | 21 | 55 | 100 | 140 | 280 |
G separation factor | 1575 | 1344 | 1372 | 653 | 640 |
KW Motor power | 2.2 | 4 | 5.5/7.5 | 11 | 15 |
Kg Weight | 460 | 800 | 1200 | 1600 | 2500 |
mm Length | 1000 | 1300 | 1700 | 2000 | 2200 |
mm Width | 750 | 1150 | 1200 | 1600 | 1700 |
mm Height | 780 | 1080 | 1100 | 1200 | 1800 |
Application Fields
Case Presentation
Company Profile
Certifications
After Sales Service
Pre-Service
1. 24 hours onlinne consult and service
2. Introduce the details of products to the customers, answer the question raised by customer at firstly;
3. Providing the operation , installation and working video for customers.
4. Providing the different solutions for choice according to the needs and requirements of customers;
Sale Service
1. Ensure new product with high quality before delivery;
2. Packing according to the export requirements and shiping carefully;
3. Provide full set of documents as customer's requirements.
4. Providing one year sparing parts for you for free.
5. Delivery on time
After-sale Service
1. Help to install and debug the equipment, Our technicians could be dispatched for
overseas service.
2. Provide 24 hours techincal support by e-mail or phone;
3. Abundant spare parts in stock are available to provide.
4. Help customers slove any other questions about products or other aspect;
5. Your workers could get trained both in our factory and yours.
Service Commitment
1. We will provide one-year warrantee to make sure your machine runs consistently. We always keep certain inventory level of spare parts, which means the replacements can be shipped to you right away.
2. Consultant services for whole machine life, 24 hours technical support by email and telephone.
3. Send technicians to the jobsite for guiding the installation and adjustment, training operators and finishing the check and accept together with you.
