Soften Treatment Softening Water Setups Remove Alkaline Hardness Equipment

Product Description

Product DescriptionCommercial RO Water EquipmentIndustrial water purification equipment is specifically designed for water treatment in industrial production, offering significant advantages in improving water quality, ensuring production process standards, and reducing operational costs.
I. Working Principle
The working principle of industrial water purification equipment is complex and precise, with core steps mainly including pretreatment, reverse osmosis (RO) treatment, and post-treatment phases:
Pretreatment Phase: Water first passes through a multi-media filter, where suspended solids, silt, rust, and other impurities are removed through granular filtration. Next, the water enters an activated carbon filter, which utilizes the adsorptive properties of activated carbon to remove organics, residual chlorine, and other contaminants. Subsequently, the water goes through a water softener, which uses ion exchange principles to remove hardness ions such as calcium and magnesium. These pretreatment steps provide favorable conditions for subsequent RO treatment.
RO Treatment Phase: Under the action of a high-pressure pump, the water passes through an RO membrane for filtration. The RO membrane is a semi-permeable membrane that only allows water molecules to pass through while blocking dissolved inorganic salts, organics, heavy metal ions, and other impurities in the water. As a result, the water is separated into purified water and concentrated water, with the purified water proceeding to the next phase and the concentrated water being discharged.
Post-treatment Phase: The purified water passes through a UV sterilizer, which uses ultraviolet radiation to disrupt the microbial structure in the water, achieving sterilization. Then, the water goes through a precision filter to further remove tiny particles and bacteria. Finally, the purified water is sent to a storage tank for subsequent use.
II. Filtration Effect
Industrial water purification equipment employs advanced filtration technologies to efficiently remove various impurities and harmful substances from water. The following are specific filtration effects and examples:
Impurity Removal: Industrial water purification equipment can remove suspended solids, silt, rust, and other impurities from water, ensuring that the outlet water is clear and transparent.
Organic Removal: Through activated carbon filters and RO membrane treatment, organics such as pesticide residues and chemicals can be removed from the water.
Heavy Metal Removal: The RO membrane has high efficiency in removing heavy metals such as lead, mercury, and cadmium, ensuring that the outlet water is safe and harmless.
Sterilization and Disinfection: UV sterilizers can disrupt the microbial structure in the water, achieving sterilization and disinfection, and ensuring that the outlet water is hygienically safe.
Taking a certain brand of industrial water purification equipment as an example, its filtration effects can meet the following standards:
Suspended Solids Removal Rate: ≥99%
Organics Removal Rate: ≥95%
Heavy Metal Removal Rate: ≥99%
Microbial Removal Rate: ≥99.9%
III. Easy Maintenance
The maintenance of industrial water purification equipment is relatively simple, mainly reflected in the following aspects:
Modular Design: Industrial water purification equipment adopts a modular design, with components connected tightly and easily disassembled, facilitating routine maintenance and component replacement.
Automatic Cleaning Function: Some industrial water purification equipment is equipped with an automatic cleaning function, which can periodically clean the RO membrane to maintain its filtration efficiency and lifespan.
Ease of Operation: The operation interface of industrial water purification equipment is simple and intuitive, allowing users to operate and control the equipment through a touchscreen or buttons.
Applications:
Drinking Water Treatment: The Commercial Purification Equipment can significantly improve the quality of tap water, removing chlorine, heavy metals, organic compounds, and other contaminants, providing residents with safe and pure drinking water.
Seawater Desalination: In coastal and island areas, RO membrane systems can convert seawater into freshwater to meet the needs of agricultural irrigation, industrial production, and domestic consumption.
Industrial Water: Reverse Osmosis Commercial plays a vital role in water treatment in industries such as electronics, pharmaceuticals, chemicals, and food. It can prepare highpurity water for precision manufacturing, laboratories, cooling systems, and boiler feedwater.
Food and Beverage: In the food and beverage industry, Commercial Reverse Osmosis is used for the purification of water used in the production of beverages, beer, spirits, health products, and more, as well as for water treatment in food processing, ensuring the sanitary quality and taste of the products.
Medical and Pharmaceutical: Water Purifier Equipment technology is widely applied in the pharmaceutical industry for the preparation of pharmaceutical water, such as water for the production of large volume parenterals, injections, tablets, and for equipment cleaning, ensuring the purity and safety of medicines. We have a variety of water treatment equipment, and we welcome you to communicate with us online.
Packaging & Shipping
Our RO Machine are packaged in specially designed export wooden crates and shipped promptly after being loaded onto containers.

Industrial Softened Water Treatment High Purity RO Reverse Osmosis Equipment
purification process	Raw water - quartz sand filter - activated carbon filter - scale prevention system - precision filter - precision filter - high pressure pump - RO system
Equipment rack	stainless steel	water production	1 ton/hour
desalination rate	99.6%	working water pressure	0.2-0.4MPa
Membrane shell material	FRP material	RO film brand	Multi-brand optional
Filter tank filling material	Quartz sand + activated carbon + resin	membrane shell	4040-1W
Precision filter	3 cores 20 inch PP cotton	voltage	110 volts/220 volts/380 volts
Solenoid valve	Brass electric valve	Flowmeter	Tubular rotor float flowmeter

Company ProfileYUFENG water treatment equipment Co.,ltd was established in 2017 and located in "capital of logistcs" Linyi city,Shandong province.We are a dedicated team of professional specializing in manufacturing household and commercial water treatment plants.The products series are included reverse osmosis,ultra filtration,ultra pure water,water softening and related accessories or consumables. Meanwhile,we supply the serivce of OEM and customized according to the requirement. We guarantee the principle of honesty and timely delivery. Providing the most suitable solution for our customers is our ultimate goal.
Q:ARE YOU A MANUFACTURER OR TRADE COMPANY?
A:We are a manufacturer in water treatment machine field more than 16 years, locatedat Linyi, Shandong. We can pick you up to visit our factory.
Q:WHAT ABOUT THE DELIVERY TIME?
A:Usually 35~40 Working days
Q:WHAT ABOUT THE MACHINE' S CAPACITY?
A: 0.25 tons/hour to 100 tons/hour
Q:IF IWANT TO BUY A MACHINE,WHAT INFORMATIONDO I NEED TO TELL YOU?
A:The testing report of raw water
B:The outflow of pure water per hour/day
C:Where is pure water used?
Q:Do you support OEM for your Reverse Osmosis Water Purifier?
A:Yes, as a water treatment equipment manufacturer, we offer OEM services.
