Roller Idler Special-Purpose Welding Machine Automatic Conveyor Roller Making Machine Conveyor Idler Roller Welding Machine
| US$11,000.00-13,000.00 | 1 Set (MOQ) |
Basic Info.
Model NO.
TH-159/220
Style
Horizontal
Frequency Range
Low Frequency
Electric Current
Inverter
Clamping Mode
Pneumatic
Spindle Speed
Stepless Speed Regulation
Operation Mode
Screen Operation
Supply Voltage
220V
Special Requirement
Customized
Transport Package
Nnon-Fumigation Wooden Box
Specification
3.8mx0.5mx1.15m
Trademark
Terok
Origin
China
HS Code
8515290000
Production Capacity
1000
Product Description
Product use and scope of applicationThe machine adopts CO2 as the protective gas of welding or the protective welding method of using flux-cored wire CO2. The welding strength is high, the center is automatically adjusted, and the welding is at the same time. The pneumatic clamping can complete the hydraulic cylinder, fire fighting equipment, roller, etc. In particular, the control system based on the imported programmable controller (PLC) is adopted to replace the traditional relay logic control circuit to make the equipment reliable. The scope of application and work efficiency have been greatly improved.Technical parameters
| project | parameter |
| model | TH-160*2200 |
| Machine tool center height | 850mm |
| Welding workpiece length | 200-2200mm |
| Welding workpiece diameter | Ф76-Ф159mm |
| welding current | 60-350A(350KR) |
| floating voltage | 45-55V(350KR) |
| rated capacity | 50KVA(350KR) |
| shield gas flow rate | 10-25L/min |
| Weldable workpiece length | 200-2200mm |
| Welding rotation speed | 0-10rpm/min |
| outline dimension | 3800x500x1150 |
| weight | 1500Kg |
