High Temperature Vacuum Kneader Hydraulic Vacuum Rubber Machine Stainless Steel Vacuum Kneader
| US$10,000.00 | 1 Set (MOQ) |
Basic Info.
Model NO.
NHZ
Application
Liquid, Liquid with Suspended Solids, Powder, Viscous Fluid
Application Area
Chemical
Certification
CE, ISO
Condition
New
Main Material
Stainless Steel
Mixing Drum Shape
Double Cone
Stirring Type
Spiral
Warranty
1 year
Working
High Speed Mixer
Power
Customizable
Heating Way
Customizable
Material
SS304
Layout Type
Horizontal
Operating Type
Cycle Operating
Mixer Type
Kneader
Transport Package
Customizable
Specification
customizable
Trademark
JCT
Origin
Foshan
HS Code
8474390000
Production Capacity
5000picecs/Year
Packaging & Delivery
Package Size
150.00cm * 150.00cm * 200.00cm
Package Gross Weight
300.000kg
Product Description
Detailed Photos
Product Description 1). Kneading machine does very well in mixing, kneading, crushing and dispersing for high-viscosity liquid materials, with no dead point.
2). Two sigma or Z-type blades.
3). Equipped with inverter for frequency control.
4). Vacuum and high pressure are available.
5). The cylinder is opened hydraulically.
6). Discharge mode: Hydraulic tilting, Bottom pumping,or Screwing.
7). With jacket outside of the cylinder, for heating or cooling.
8). Heating mode: Hot oil, Electric or Steam.
9). All the parts that contact with material are made of stainless steel.
| Model | Chamber Volum(L) | Drive motor power (KW) | Mixing Speed (rpm) | Discharge mode | Heating | |||||
| Full volume | Feeding amount | Paddle fast / slow paddle | Optional parameters | Optional parameters | ||||||
| NHZ-5 | 5 | 3 | 2.2-4 | 75/50 | Manual / Hydraulic tilting | Running Hot oil | Electrical heating | Pressure Steam | ||
| NHZ-20 | 20 | 12 | 3-5.5 | 63/42 | ||||||
| NHZ-50 | 50 | 30 | 4-7.5 | 63/42 | ||||||
| NHZ-100 | 100 | 60 | 5.5-7.5 | 43/29 | ||||||
| NHZ-200 | 200 | 120 | 7.5-15 | 43/29 | Hydraulic tilting | The bottom pumping | Screw extruding | |||
| NHZ-300 | 300 | 180 | 11-18.5 | 43/29 | ||||||
| NHZ-500 | 500 | 300 | 18.5-30 | 43/29 | ||||||
| NHZ-1000 | 1000 | 600 | 22-55 | 32/22 | ||||||
| NHZ-1500 | 1500 | 900 | 30-90 | 32/22 | ||||||
| NHZ-2000 | 2000 | 1200 | 45-110 | 32/22 | ||||||
| NHZ-3000 | 3000 | 1800 | 55-130 | 33/22 | ||||||
| Remarks: 1,Temperature range: 0-300°, 2, Pressure range:-0.1-0.6MPa, 3,Inverter for frequency control if necessory. | ||||||||||
Chewing gum base kneading, rubber base kneading, DOW Corning, sealant,Silicone sealant, adhesive, ink, dope, pigment, dye, carbon, CMC, cosmetic, foodstuff, battery, medicine, plastic and other viscosity fluid etc. Vacuum kneading machines.
