Automatic Bottle Jerrycan Disinfectant Oil Liquid Weighing Filling Machine with Capping Labeling Line

Product Description

Introduction:
1. This automatic liquid oil paste paint weighing filling machine with capping sealing line is suitable for various liquid gel paste auto packaging into various barrel, jerrycans, tubs or plastic jars from 5kg to 20kg (200kg available too) etc;
2. with its highly efficiency and filling precision , it's widely used for big volum packaging in foodstuff, daily chemical, chemical, pesticides ect fields, like ketchup filling, sauce filling, tub butter filling, oil filling, liquid detergent filling, paint filling, glue fiilling, liquid reagent and pesticide filling etc.
Main features:
1. This series automatic bottle weighing filling machine adopts pump/gravity to feed materials & electronic scaling tech to measure the doage, and suitable for various liquid, viscous liquid, sauce and paste filling of various big bottles and buckets; with high filling precision,
2. Adopting servo conveying belt for bottle separating & positioning, it's very easy & quick to adjust for different bottles filling, economical and practical, with higher filling efficiency.
3. Adopting the scale weighing way to monitor in time the current filling quantity and feedback it to the controlling instrument, the controlling instrument outputs the controlling signal for the fast & slow filling based on the set data, realizing the fast rough filling and accurate slow filling for the fairly large filling dosages.
4. With PLC system to control & touch screen, it's easy to adjust & operate.
6. Can be equipped with servo capping, labeling & conveying machines based on capacity & needs.
auto 6-nozzle liquid weighing filling with diving-type filling nozzles to reduce foams fyi
Technical parameters:(professionally customized based on bottles, layout, product, process etc)

model	BNAPL-W4	BNAPL-W6	BNAPL-W8
Filling dosage (fyi)	0.05-1kg	5kg-30kg	1-5kg (customized )
Filling nozzle	4-nozzle weight filling	6-nozzle	8-nozzle
Capping choose	multifunctional capper	grab-type servo capper	customized
capacity (5-20L)	1000-1500BPH	400-800BPH	1000-1500BPH
Filling error	±0.5%
Voltage	220V/380V 50/60HZ
Air pressure	0.4-0.6Mpa

auto 6-nozzle liquid cleaner/disinfectant weighing filling + servo capping + labeling line fyi, 30kg, 360-450BPM
30kg bottle/barrel/tub/jerrycan liquid deteergent/disinfectant filling line details
6-head liquid weighing type filler with gravity liquid feeding fyi auto 1-head servo capper, accurate & stable
6-head liquid weighing type filler operation screen fyi auto 1-head or 2-head servo tracking capper, accurate & stable
semi-auto liquid weight filling machine for 20-100kg fyi
automatic sauce paste bucket weight filling capping machine with manual bucket feeding and cap feeding fyi
explosion-proof semi-auto paint/liquid filling capping machine (can be pressing or crimping)
30kg bottle/jerrycan liquid oil filling + cap-pressing line fyi, customizing based on bottles & capacity :)

auto jerrycan/bottle 4-nozzle ink/paint weighing filling + auto capping + induction sealing fyi
(1-5L, 1200-1800BPH)

Boasting with a professional team & perfect teamwork, we are sufficient to complete very well
the filling packing turnkey projects' design, production, installation & training. Welcome to inquire~
Baoneng Machines packaging before delivery fyi
Meticulous design, Technical Innovation, Rigorous Manufacturing & Attentive service is Our Quality Guidelines we have been carrying out. Welcome to inquire & visit our factory in Guangzhou China.
