Sandblasting Drilling Holes Removing Paint Glass Mirror Stainless Steel Laser Engraving Machine Automatic Laser Marking Machines

Product Description

Product Description
Advantages of the new high-precision large format mirror marking machine: 1: One machine has multiple functions, it can remove paint, sand and punch holes on mirrors. It can also mark on various metals, glass, mirrors, some plastics and other non-metallic materials. 2.Marking system supports:single line,filling engraving,bitmap engraving.number skipping,coding,etc.
3: The independently developed gantry machine tool structure is rigid and stable, which avoids machine vibration during processing and improves processing accuracy.
4: The mobile guide laser marking machine can follow and mark a wide range of objects. The overall structure is simple and compact with high stability.
5: Equipped with automatic smoke removal device to ensure clean and environmentally friendly processing.
Detailed Photos
High-speed galvanometer
Adopt high-speed swing motor, support assembly line marking speed 10000mm/min.
Scanning Lens
Made of quartz material has a lifespanof over 5 years,Ensure uniform distribution ofhigh-quality light spots.
Computer & Bracket
The computer is equipped with the Win 10 system.The bracket is designed with human mechanics and is suitable for long-term operation,Can rotate 180°.
Grinding Level Guide Rail
High precision linear guide rail, with good rigidity and high accuracy, with a running accuracy of 0.02 mm, dustproof and rust proof, and simple maintenance
Smoke Exhaust Outlet
The smoke generated during the marking process is easy to exhaust.
Automatic oiler
Automatic oil supply at a fixed time and in a fixed quantity, high efficiency, no manual operation required.
Product Parameters

Model Name LR-1325/1530FM Fiber Laser Marking Machine Laser light source MOPA Pulsed Laser Laser power 60W,100W, 200W wavelength 1064nm Beam quality M=1.5 Standard marking area 1300*2500mm,1500*3000mm Marking depth ≤2mm Minimum character size 0.05mm Repeat positioning accuracy ±0.01mm Splicing accuracy ±0.01mm Marking speed 600-1000 characters/second Cooling system Water Cooling Power consumption <1kw Minimum line width 0.01mm Working power supply Customizable Supported formats CDR, Al, DXF, PLT and other vector file formats Applicable Materials Metals and various non-metallic materials: high-hardness alloys, oxides, electroplating, coatings, ABS glass, mirrors, engineering plastics, etc.

Company Profile
We offer a three-year warranty maintenance policy for the entire machine. During the warranty period, if any parts are damaged due to the machine's own reasons, we will provide you with free parts for replacement.
Machine lifetime free maintenance and free software updates. If you need it, our engineers can provide technical support on-site in your country. Before the machine is shipped, we will provide you with comprehensive instructional videos.
7 * 24-hour service, whether on weekdays or weekends, upon receiving a fault report, respond within 10 minutes through online chat, phone, fax, or email, and find the cause of the fault within 60 minutes.
We provide lifelong free technical support, machine installation, drawing and programming, machine operation, machine maintenance, and lifelong after-sales solutions for our customers.
Certifications
FAQ
1.Are you a factory or a trading company?
We are a factory with an export license.
2.Can you do OEM?
Yes, We have been cooperating with many trading companies and OEM manufacturing for few years.
3. What is after-sales service?
We have 17 years of after-sales service experience. No matter what problems your machine has we will respond within 10 minutes and solve them within 2 hours. The entire machine comes with a 3-year warranty and technical support is provided through phone, email, WhatsApp, and Skype
4.How to choose the appropriate machine?
You can tell us about the material, size, and machine function requirements of the workpiece. We can recommend the most suitable machine based on our experience.
5.Do you have installation and equipment debugging services?
Yes,we do. The machine has been installed and debugged before leaving the factory. After receiving the machine, you can use it directly. We provide a complete and free operation manual and instructional video and as well as we can also have our technical personnel go to your country to install and debug the machine.
6.Can the machine be customized according to my requirements?
Yes,customization is possible. We have a professional team with professional experience. Our goal is to satisfy our customers.
7.Can I process a sample video to confirm the machine's functionality?
Yes you only need to provide drawings or photos, and we can provide you with free processing samples and recording videos.
8. What are the payment methods?
There are two payment methods.
(1)T/T refers to international bank transfers. 50% deposit, then we start to produce machines for you. 50% before shipment convenient and fast.
