Biogas Upgrading CNG Project Containerized Explosion Proof High Pressure Water Cooling Landfill Marsh Bio Gas Screw Compressor
| Negotiable | 1 Piece (MOQ) |
Basic Info.
Model NO.
KG315-16(G)
Lubrication Style
Lubricated
Cooling System
Air Cooling
Cylinder Position
Angular
Structure Type
Closed Type
Installation Type
Stationary Type
Type
Twin-Screw Compressor
Color
Blue
Suction Pressure
30-100 Mbar(G)
Intake Temperature
3-40 ºC
Working Pressure
5.5 - 7 Bar(G)
Gas Capacity
92 Nm3/H
Noise Level
85±3 dB(a)
Motor
Exdiibt4
Nominal Power
250 W
Nominal Speed
1460 Rmp
Discharge Pipe Connections
3/4"
Transport Package
Standard Export Package
Specification
ISO, CE
Trademark
Adekom
Origin
Dong Guan
HS Code
8414809090
Production Capacity
100 Per Month
Product Description
Explosion Proof Screw Gas Compressor for Biogas MarshADEKOM Well Head Gas Screw Compressor, uses the most advanced, mature screw air compressor's main motor and proven by European markets mature application experience, Water Cooling Gas Compressor providing the optimal solution while leading the new trend of environmental protection and energy saving.
ADEKOM Stationary Screw Compressor is suitable for applications where low inlet pressure, because of the screw compressor few moving parts, less maintenance workload, high reliability, is technology further ascension for the use of biogas piston compressor.
While, we are specialized in providing compressed air products and solution to our customers all over the world. Our JV manufacturing facility is in Southern China and that our financial & logistics headquarter is in Hong Kong. Our procuct range includes Standard screw air compressor(3kW-315kW), Low and Hight pressure rotary screw air compressor, Oil free screw/scroll compressors,VSD inverter controlled screw compressors,Railway application compressors,Underground application compressors,Biogas/Landfill gas compressor, CNG / LPG application compressors,Refrigerated air dryers,Dessicant air dryers and Inline air filters/water separator.
Technical Paremeters
| Model | K5.5(G) | KA7(G) | KA11(G) | KB15(G) | KB18(G) | KB22(G) | KC30(G) | KC37(G) | KC45(G) | KD55(G) | KD75(G) | |
| Volume capacity | Nm3/h | 45 | 62 | 92 | 125 | 160 | 185 | 255 | 318 | 390 | 470 | 680 |
| Air flow temperature | °C | Air-cooled: ambient temperature +8~10°C | ||||||||||
| Residual oil content | mg/m3 | <=3 | ||||||||||
| Noise level | dB (A) | <=68±3 | ≤69±3 | ≤71±3 | ≤72±3 | ≤75±3 | ||||||
| Power supply | V/ph/Hz | 3/380-415/50 | ||||||||||
| Motor | ExdIIBT4 | |||||||||||
| Starting method | Direct driven | Star-Delta Starting | ||||||||||
| Nominal power | kW | 5.5 | 7.5 | 11 | 15 | 18.5 | 22 | 30 | 37 | 45 | 55 | 75 |
| Nominal speed | rpm | 1440 | 1440 | 1460 | 1460 | 1470 | 1470 | 1470 | 1475 | 1475 | 2965 | 2965 |
| Protection class/Insulation class | IP55/F | |||||||||||
| Fan | ExdIIBT4 | |||||||||||
| Nominal power | W | 180 | 180 | 250 | 550 | 1500 | 2200 | |||||
| Nominal speed | rmp | 1400 | 1400 | 960 | ||||||||
| Blowing rate | m3/h | 1200 | 2750 | 9300 | 15000 | 23000 | ||||||
| Intake pressure | mbar(g) | 30-100 | ||||||||||
| Intake temperature | °C | 3-40 | ||||||||||
| Relative humidity | % max. | 100 | ||||||||||
| H2S (hydrogen sulfide) | ppm max | 1500 | ||||||||||
| Working pressure | bar(g) | 7 | ||||||||||
| Max. working pressure | Bar(g) | 7 | ||||||||||
| Mini. working pressure | Bar(g) | 5.5 | ||||||||||
| Mini/max ambient temperature | °C | 0/40 | ||||||||||
| Connections | ||||||||||||
| Suction pipe connections | inch(mm) | 1 1/2" | 2" | DN80 | DN100 | |||||||
| Discharge pipe connections | inch | 1/2" | 3/4" | 1" | 1 1/2" | 2" | ||||||
