6h Multi-Functional Vertical Turret Milling Machine with High Quality and Performance

Product Description

Product Description
Characteristics of Vertical and Horizontal Milling Machine
Revolutionary Variable Spindle Axis Direction: The NT40 Horizontal Spindle Mill offers unmatched versatility with its unique ability to alter the spindle axis direction. This feature allows seamless adaptation to various processing demands, significantly enhancing both flexibility and processing efficiency.
Unmatched Power and Versatility: Thanks to the innovative adaptability of the spindle axis, the NT40 Horizontal Spindle Mill provides an incredible range of functionalities. It effortlessly processes workpiece surfaces at diverse angles relative to the horizontal plane, catering to an extensive array of processing requirements.
Remarkable Adaptability: Designed for complex processing tasks, this dual-purpose milling machine excels in plane, surface, and specialized angle processing. Simply adjust the spindle axis direction to achieve superior results in a multitude of intricate applications.
Enhanced Production Efficiency: The NT40's ability to modify the main shaft axis direction allows for multi-surface processing post a single setup. This innovative feature minimizes repositioning time, leading to remarkable improvements in production efficiency.
User-Friendly Operation: Despite its robust capabilities, operating the NT40 Horizontal Spindle Mill remains effortlessly simple. Users can easily switch between vertical and horizontal modes with intuitive controls, adapting swiftly to diverse processing requirements.
Product Parameters
Structural Characteristics of Vertical and Horizontal Milling Machine
1. Bed Structure
The bed of this sophisticated milling machine boasts a double-column design, ensuring exceptional strength and rigidity, which translates to high precision and stability. It is equipped with a sliding bed to support the table and spindle, effectively reducing vibration and noise for optimal performance.
2. Workbench Structure
The workbench plays a pivotal role in the NT40 Horizontal Spindle Mill, securing the workpiece firmly during processing. Designed with a user-friendly T-slot, it facilitates easy workpiece clamping and offers movement in both horizontal and vertical directions. The table's rotatable design further supports bevel machining, enhancing overall versatility.
3. Main Shaft Structure
Featuring either a vertical or horizontal spindle structure, the NT40 is equipped with a robust tool clamping system using a chuck or tool handle. Its high-speed, high-torque spindle meets a variety of machining needs, while an integrated cooling system ensures efficient cooling of both tools and workpieces.
4. Feed System
Integral to the NT40's performance, the feed system comprises a feed shaft, a precise servo motor, and a reliable guide rail. It governs the tool's movement in both horizontal and vertical planes, facilitating diverse machining processes. The servo motor enables precise feed shaft control, ensuring high precision and rapid operation, while the guide rail maintains system stability and accuracy.
5. Structural Advantages
The NT40 Horizontal Spindle Mill stands out with its compact, highly functional design. Its wide application range, high accuracy, and substantial automation capabilities make it ideal for efficient processing. This machine reduces manual intervention, saving both time and costs, offering a sophisticated solution for modern manufacturing needs.

Product name	Vertical and horizontal milling machine
Product model	6HV
Product technical parameters
dimension	Table size	1372*330MM
	Table load	350KG
journey	Left and right travel (X)	1000MM
	Forward and backward travel (Y)	420MM
	Up and down travel (Z)	380MM
Vertical spindle coefficient	Spindle taper	NT40
	Distance from spindle to table	150-530MM
	Spindle speed	80-5440RPM
	Spindle lift stroke	127MM
	Spindle horse power	5HP
	Arm reach	600MM
Transverse spindle coefficient	Horizontal shaft motor power	2.2KW
	Transverse spindle speed	60-1320RPM
	Transverse spindle taper	NT40
	Transverse spindle travel	120
	Bracket center height	230
Machine profile dimensions	T-slot (width * Slot number * slot distance)	16MM*3MM*65MM
	Milling head tilt Angle	45 front/back side
	Machine size (L * W * H)	2200*2000*2500MM
	Approximate machine weight	2500kgs
	Accessories name and specification	quantity
Standard parts for machine tools	1.Hand oil pump	1
	2.Work light	1
	3.Organ board + protective glue	1
	4.Vertical NT40 tie rod, horizontal NT40 tie rod	1
	5Tools and toolboxes	1

Special parts for machine tools	6.Two axis electronic ruler	1
	7.X-axis automatic feed	1
	8.6 "flat pliers	1
	9.58 piece composite platen	1
	10.NT40 cable nozzle	2
	11. Operation instructions	1
	12.Z axis lifting motor	1
