High Efficiency Crushing Equipment High Capacity Jaw Crusher Material Handling Equipment

Product Description

Product Description
Heavy Duty Crusher for Efficient Stone Crushing and Mining Applications
Production Description:
Step into the future of stone crushing with our revolutionary jaw crusher, a marvel of engineering crafted to deliver unrivaled production capacity and unparalleled efficiency. This formidable machine is meticulously designed for the primary crushing of both hard and medium-hard stones, transforming your operations with its substantial crushing ratios and remarkable efficiency. Built to conquer a diverse array of ores with compressive strengths reaching up to 320MPa, it produces perfectly sized medium particles in a singular, efficient pass. Its seamless adaptability allows it to integrate effortlessly with cone crushers, impact crushers, sand-making machines, and a plethora of other equipment, forming a comprehensive sand and gravel production plant that meets all your operational needs.
As a cornerstone in limestone stone crushing, our versatile jaw crusher range is tailored to meet every conceivable requirement. Spanning from the adaptable PE-400×600 to the formidable PE-900x1200, each model is precisely engineered to address specific crushing needs, ensuring both efficiency and precision in your operations.Mining Equipment Application Process:
The operation commences with the transportation of stone by truck to
our powerful jaw crusher. This is achieved through an efficient and reliable feeder system that guarantees consistent, optimal performance.
Following this, the fragmented material undergoes meticulous screening through a state-of-the-art high-performance vibrating screen,
culminating in a thorough sand dewatering process via cutting-edge spiral or roller sand washing machines, which ensures the production of superior quality output.
Other Products:
Product Parameters

Model	Size of feed opening (mm*mm)	Speed (r/m)	Max feed size (mm)	Motor power (kw)	Capacity(t/h) Closed side setting (mm)
					100	125	150	200	225	250	300
PEW-4230	1060*750	230	630	90-110	180	210	237	294	350
PEW-4836	1200*900	200	760	110-160	210	250	280	320	402
PEW-4840	1200*1000	200	850	132-160		265	302	370	480
PEW-6048	1500*1200	190	1000	185-250			415	520	580	660	750

Model	Feeding opening(mm)	Feeding size(mm)	Discharging size(mm)	Capacity(t/h)	Rotation speed of eccentric shaft (r/min)	Power(kw)	Weight(t)	Dimensions(mm)
PE-150x250	150x250	125	10-40	1-3	350	5.5	0.6	720x660x850
PE-250x400	250X400	210	20-60	5-20	300	15	2.8	1450x1280x1350
pe-400x600	400x600	340	40-100	16-60	275	30	7	1730x1730x1630
PE-500x750	500x750	425	50-100	40-110	275	55	12	1980x2080x1870
PE-600x900	600x900	500	65-160	60-200	250	75	20	2290x2290x2400
PE-750x1060	750x1060	630	80-140	115-330	250	110	29	2660x2430x2800
PE-900x1060	900x1060	685	230-290	160-400	250	110	33	2870x2420x2940
PE-900x1200	900x1200	750	95-165	220-450	200	110	52	3380x2876x3330
PE-1000x1200	1000x1200	850	195-265	315-500	200	110	55	3480x2876x3330
PE-1200x1500	1200x1500	1100	150-300	400-800	180	160	100.9	4200x3300x3500
PEX-150x750	150x750	120	18-48	8-25	320	15	3.8	1200x1530x1060
PEX-250x750	250x750	210	25-60	13-35	330	30	5.5	1380x1750x1540
PEX-250x1000	250x1000	210	25-60	16-52	330	37	7	1900x1400x1400
PEX-250x1200	250x1200	210	25-60	20-61	330	45	8.5	2140x1660x1500
PEX-300x1300	300x1300	250	20-90	16-105	300	75	11	2400x1950x1700

Jaw Crusher Application:
1. Immerse yourself in the world of robust operations with our jaw crusher, a cornerstone of efficiency meticulously crafted to conquer the challenges of medium and fine crushing of the most resilient ores and rocks. This essential equipment demonstrates its prowess across a multitude of industries, including metallurgy, mining, chemical engineering, cement production, construction, refractory materials, and ceramics. Revel in its unwavering strength and reliability, bringing outstanding benefits to each application.
2. Experience the pinnacle of engineering excellence with our jaw crusher, designed for unmatched performance to handle both hard and soft ores with compressive strengths up to 300MPa. From pebbles and granite to quartz and construction debris, this versatile machine effortlessly crushes an extensive array of materials such as calcite, concrete, limestone, coal gangue, ferrous silicon, basalt, sandstone, rock salt lumps, and iron ore. Its remarkable adaptability ensures it seamlessly meets diverse operational demands.
3. As a dominant force in primary crushing, the jaw crusher is a vital component in both the aggregate and mineral processing industries. Its influence extends beyond, showcasing exceptional performance in construction material recycling, metallurgy, chemical industries, power generation, water conservancy, transportation, and countless other applications. Its versatile capability and steadfast reliability make it an invaluable asset across sectors.
Jaw Crusher Operating Principle
Unleashing the dynamic power of its motor, the jaw crusher performs with precision and finesse. Through the motor's wheels and a triangle belt, alongside a slot wheel, it sets the eccentric shaft in motion, orchestrating the rhythmic movement of the moving jaw plate. This cohesive action efficiently crushes materials within the crushing chamber, formed by the fixed jaw plate, moving jaw plate, and side liner, facilitating a smooth and efficient discharge through the discharging opening. This engineered precision guarantees optimal performance and reliability.
Feature of PE 250*400 Jaw Crusher
1. With an impressive high crushing ratio, this machine exudes reliability with its easy maintenance, making it a trusted choice for all your crushing needs. Its robust construction and ease of care underscore its dependability, ensuring seamless operation.
2. It consistently delivers a uniform final grain size, significantly elevating the quality of the output material. This precision engineering highlights its superior design and manufacturing excellence, catering to exacting standards.
3. With its straightforward structure, the jaw crusher minimizes operating costs, substantially enhancing operational efficiency and profitability. This simplicity in design leads to reduced time and resources spent on maintenance, boosting overall performance and profitability.
4. It ensures reliable operating conditions, providing unwavering performance and peace of mind with every use. This reliability guarantees continuous productivity, making it a steadfast partner in your operations.
Certifications
Company Profile
Shandong Huimin Lusheng Metal Products Co., Ltd. stands proudly as a beacon of modern innovation within the manufacturing domain, leading the charge in crafting cutting-edge screening equipment, crushers, and a vast array of accessory machinery. As a revered leader in our industry, our exceptional team of professionals shines in both research and development and production efficiency. We meticulously design bespoke solutions tailored to meet your specific mining machinery demands. Our expansive product lineup includes Jaw Crushers, Cone Crushers, Impact Crushers, Vertical Impact Crushers, Hammer Crushers, Vibrating Feeders, Vibrating Screens, Sand Washers, and Belt Conveyors. Enhancing our offerings, we provide premier Grinding Machinery including Raymond Mills, High-pressure Suspension Mills, Ultrafine Mills, Roller Mills, and Ball Mills. These exceptional machines are utilized extensively across numerous sectors such as mining, construction materials, chemicals, metallurgy, transportation, and hydraulic engineering.
With an unwavering commitment to modernization and a vision for global market supremacy, we tirelessly integrate elite management, celebrated scientific researchers, and highly skilled graduates into our dynamic team. By harnessing cutting-edge technology from the United States, Germany, Japan, and other leading nations, we drive self-innovation, achieving remarkable breakthroughs that set unprecedented standards in the industry.
Our company is unwaveringly dedicated to delivering not just premium quality products at the most competitive prices, but also expertly curated guidance on equipment selection and optimum solutions precisely tailored to your needs, ensuring unparalleled satisfaction.
Harnessing our formidable research and development and production capabilities, along with our rigorous quality assurance and sterling reputation, we are committed to not only meeting but exceeding all of our customers' expectations. We warmly welcome friends from various sectors to visit, guide, and engage in enlightening business discussions. Do not hesitate to reach out for any inquiries.Packaging & Shipping
Our Advantages
1. Uncover an exceptional synergy of efficiency and impressively low energy consumption that propels it to a level of performance like no other, distinguishing itself as a leader in the industry.
2. Crafted with an elegant simplicity yet boasting remarkable strength, this design pledges easy maintenance alongside enduring durability, ensuring it withstands the test of time effortlessly.
3. Embrace the benefits of a fully enclosed design that guarantees zero dust pollution, maintaining a pristine and safe working environment that enhances operational integrity.
4. Depend on the steadfast reliability of a stable workstation, complemented by smooth, seamless operations that perform flawlessly with each use, promising consistency in every task.
5. Amplify productivity through superior screen utilization, offering an expansive unit area that effectively prevents clogs and facilitates swift, hassle-free screen changes.
6. Attain unparalleled precision with a screening accuracy of 96% or more, coupled with a robust processing capacity that makes it the perfect choice for the most challenging applications.
After Sales Service
1. Pre-sale Services:
(1) Benefit from our expert guidance as we assist you in selecting the ideal equipment model that perfectly aligns with your specific requirements; allowing you to make informed decisions and maximize your investment.
(2) We offer custom design and manufacturing services to create products that meet your unique specifications with precision and quality; crafting solutions that are tailored to enhance your operational capabilities.
(3) Receive comprehensive training for your technical team to ensure they achieve operational excellence, empowering them with the skills needed for success and driving unparalleled performance in your operations.
2. Services During the Sale:
(1) Experience peace of mind with our thorough pre-delivery inspection, guaranteeing the highest level of product excellence and reliability; ensuring your equipment meets the highest standards before it reaches your hands.
(2) Our team collaborates closely with you to design effective problem-solving strategies, ensuring seamless integration and operation of your new equipment; facilitating a smooth transition and enhancing productivity.
3. After-sale Services:
(1) Leverage our expert assistance as we help you plan your initial construction scheme for maximum efficiency; optimizing your setup for peak performance and long-term success.
(2) Enjoy professional installation and debugging services, ensuring your equipment performs optimally right from the start; unleashing the full potential of your new machinery effortlessly.
(3) Benefit from on-site training for your first-line operators, ensuring a smooth and successful operational transition with confidence; equipping them to handle challenges competently and efficiently.
FAQ
Q1.Are you a manufacturing or trading company?
A1.We are a manufacturer/ factory, established in 2010.
Q2. How long is the warranty? Does your company supply the spare parts?
A2.One year(Calculated from the equipment arrives the customer's side.). Spare parts for you at the lowest cost.
Q3.What about Warranty? What will we do if the machine is broken down?
A3.The warranty period for all of structural and mechanical equipment is one year. The warranty period for all electric motors is half one year. Wear parts are not covered by warranty unless the component part is found to be flawed.
Q4.What is your payment method?
A4.30% deposit in T/T advance, 70% balance before shipment.
Q5. If I need the complete crushing plant can you help us to build it?
A5.We can help you set up a complete production line and provide related professional advice. We had already built many mining projects in China & Overseas.
Q6.What's the after sale service of your company?
A6.We will provide foundation drawing and video to the clients for installation. Besides, we can provide guidance service for installation and operation of workers, etc.
Q7. Can your company provide wearing parts?
A7.We can deliver you the spare parts within 10 working days after your order. If your equipment are not manufactured by our company, please provide us the wearing parts drawing or number.
Q8.What should we need to do for if we want to get a best quotation?
A8.If you want us recommend a suitable type for you; please let us know the below informations:
1).What products does the equipment screen: _____
2).Input/Output size: _____
3). Moisture:_____%
4). The capacity (tons per hour) _____
5). Voltage:______V,Frequency:______HZ, 3 phase
6). Material type:Q345R carbon steel?
Q9.What services are available?A9.Professional engineer design the production line for you. Pre-check and accept products before delivery.Professional technical guidance for installation
