Upright Trinocular Metallurgical Microscope Dark & Bright Objective Lens, 50X - 400X

Product Description

Product Description Upright Trinocular Metallurgical Microscope Dark & Bright Objective Lens, 50X - 400X
Introduction:
E-8500 series upright metallurgical microscopes are suitable to observe surface of opaque object or transparent object. They are equipped with excellent UIS optical system and modularization function design so that provided excellent optical quality and operation performance, update system expediently and provided observation in reflected or transmitted and mixed illumination, polarizing observation, dark field observation. These instruments have beautiful sculpt, convenient control and clear image. They are the ideal instrument in research work in biology, metallography, mineralogy, precision engineering, electronics, ect.
Product Parameters Technical specifications:

Model	E-8500
Eyepiece	Wide field WF10X (Φ22mm)
Infinity long-range flat field achromatic objective lens	PL 5X/0.12 (no cover glass)
	PL L10X/0.25 (no cover glass)
	PL L20X/0.60 spring (no cover glass)
	PL L40X/0.75 spring (no cover glass)
Eyepieces tube	Trinocular, 30° inclined, (Built-in polarizer for switching)
Epi-illumination system	12V 50W, Halogen lamp, lightness adjustable
	Vertical illumination With field diaphragm, aperture diaphragm and polarizer, (Yellow, Blue, Green) filter and frosted filter
Focus system	Coaxial coarse / fine focus system, with tensional adjustable and up stop, minimum division of fine focusing: 2μm.
Transmission lighting system	Abbe condenser NA.1.25 Rack & pinion adjustable
	Blue filter and frosted filter
	Light Collector for halogen lamp
	12V 30w halogen lamp, brightness adjustable
Nosepiece	Quintuple (5 holes) Backward ball bearing inner locating
Stage	Double layer mechanical (Size: 210X140mm, moving range: 63X 50mm)
Dimension, N.W	260 x 280 x 498mm, 11kg
Packing size, G.W	360 x 320 x 670mm, 13kg

Metallographic Image Analysis Software (Optional Purchase)
1. Introduction
This software can be used with a variety of metallographic microscope to complete the metallographic image acquisition, processing, analysis, report generation and other functions; also have to view the library, geometric measurement, fixed-fold printing, image stitching, image contrast, confocal ), Three-dimensional light maps and other functions. Compared with the traditional manual method, the sample software for metallographic image analysis, with the following advantages:
save the traditional darkroom camera system, directly with a digital camera to take pictures, photos can be saved or printed.
can be compared on the computer map and standard query, do not read the standard books.
can be quickly and accurately automatically calculate the various types of microstructure of the perimeter, area, long axis, short axis, equivalent circle diameter,
Aspect ratio, area percentage and other geometric shape parameters, than the previous manual calculation method has greatly improved.
quantitative metallographic standards can be applied to automatically calculate the level, the level of results to allow human intervention.
can automatically generate the electronic document inspection report, the report can be saved as WORD, EXCEL, PDF and other documents.
The whole inspection process is complete on the computer, to achieve office paperless, greatly enhance the level of enterprise information.
