Basic Info.
Max. Working Size
1800X800mm
Min. Working Size
150X150mm
CNC
Servo Motor+ Ball Screw+Linear Guide Rail
Overall Size
3000X1150X1800mm
Transport Package
PE Film
Specification
3000x1150x1800mm
Production Capacity
10 Sets/ Month
Product Description
High Frequency Precision Frame Assembly Machine
1.Introduction:
High Frequency Precision Frame Assembly Machine is updated system for high precision miter door assembling. CNC system is integrated with high frequency technology.
2.Features:
1. Servo motor, ball screw, and linear guide rail can make sure the high quality of assembling (diagonal tolerance is less than 0.5mm).
2. High frequency technology only heats glue line without wood, which can help customer save the time (5-15 seconds can finish one door assembly) and electricity (Each frame costs is less than 0.06KWh).
3. HF Precision Frame Assembly Machine is controlled by PLC automatically. Easy to learn and convenient to operate. It is the best choice for wooden door, PVC wrapped door assembly such as photo frame, cabinet door, closet door, as well as other kinds frame and doors.
4. Machine is multi-functional, which can also assemble 90 degree and 135 degree corner frame with or without tenon.
3.Parameters:
| Model | HFPM-1880-LD | HFPM-2880-LD |
| Max. Working size | 1800x800mm | 2800x800mm |
| Min. Working size | 150x150mm | 150x150mm |
| CNC | Servo Motor+ ball screw+linear guide rail |
| Output power | 5KW | 5KW |
| Overall size | 3000x1150x1800mm | 4000x1200x1800mm |
| Weight | 1000kg | 1200kg |
