Environmentally Friendly Waste Tyre Pyrolysis Plant /Plastic to Oil /Convert Waste Tyre to Fuel Oil 2800-6000

Product Description

1.Plant features
A) one machine can be used for several material
such as tyre ,plastic.,medical waste,oil sludge etc
B) environmental friend:
we have 3-level dedust system ,non black smoke go to air
carbon discharge is in sealing way ,no carbon powder fly in air
water is recycling ,so non pollution
C) safe
we have fully safety device ,such as safety valves ,emmergency hole, alarming system etc.
2.About oil rate for different material

Oil yied/day	Waste tire/ rubber	Big tyres	45%--50%
		Car tyres	40%
		Bicycles and motorcycles tyres	30%--35%
	Waste plastic	Fishing net	45%--50%
		Safety net , farm-oriented film
		Conwenient bags , weave bags	40%
		Off cut of recycled paper mill	20%--30%

3.Plant specification

Specification	Capacity	Raw material	Heating material	Working time (hrs)	Shipped by
XHZT-2200-6000	5Ton	Waste tyres Cables Plastics Rubber Oil sludge	Wood,coal ,oil,gas	12	2*40HQ
XHZT -2600-6000	8Ton			15	1*40HQ+1*40FR
XHZT -2600-6600	10Ton			18	1*40HQ+1*40FR
XHZT -2800-6000	10Ton			18	1*40HQ+1*40FR
XHZT -2800-6600	12Ton			20	1*40HQ+1*40FR
XHZT -2800-6600	15ton	Medical waste		22	1*40HQ+1*40FR
Contiuous plant	20Ton	Other waste		24	3*40HQ
Contiuous plant	60Ton			24	5*40HQ

4.Power consumption

model	Draft fan	speed reducer	water pump	oil pump	4blowers
2200*6000	4kw	3kw	1.5kw	1.5kw	1kw
2200*6600
2600*6000	7.5kw	5.5kw
2600*6600
2800*6000
2800*6600

5.Working principle

1.Feed raw materials: The raw material can be waste tire/waste plastic/waste rubber. Always feed by the auto feeder.

2.Pyrolysis: Include a reactor and catalyst room. Heat the reactor by coal/wood/oil/natural gas. This part will produce high temperature oil gas, the oil gas then flow into the next system.

3. Condensing: Oil gas come out from the reactor and catalyst chamber then cooling down in this part. Condensing system include condenser pipe, oil water separator, horizontal condenser and waste gas condenser. This will make the oil yield to the maximum.

4.Waste gas recovery: This part mainly deal with the gas that cannot be condensed. The whole process is very steady and high efficiency.

5. Discharge: After finished oil produce, the temperature of reactor can be cooled down, When the temperature falls down to 40 degree then carbon black can be discharged automatically by the way of anticlockwise rotate the reactor. The carbon black will drop into slag pool and then use screw conveyor to clean the slag pool. After discharging the carbon black, we can discharge the steel wire. There is steel wire hook in the auto-feeder, we only need put the steel wire hook into the reactor, and start the motor, the steel wire can be pulled out easily, there is no need for workers to contact the reactor, it is very convenient.

6.Payment term and delivery:
30% TT deposit, balance paid by Sight LC/ 100% Sight L/C
Delivery with 15-20 days after getting advance payment or Sight L/C
7.After-sale service:
1. Delivery time-- It will be within 15 working days after we receive the deposit.
2. Warranty- The warranty period is 2 Years(Other suppler offer 1 year warranty), engineers available to service at any time.
3. Installation and Training-- Our Company will dispatch technician to guide installation and training for free, ensuring the operation safety. The installation period shall be one month; otherwise, buyers will pay extra salary for the technician with the price of USD 60.00 per day.
4. 24-Hours telephone service .
Regular phone visiting to check out if there is anything we can do for you, maintenance guiding, easily worn-out parts and catalyst offering, on-site maintenance.
Remarks:
A. we can produce machine according to your requirements.
B. Delivery time can be shorten according to your requirement.
C. We can offer other vicinity device according to your requirement.
