Ml-500mm Ge Cable Plum Blossom Take up Machine Square or Round Paper Drums and Cartons

Product Description

Product Description
Plum Blossom Barrel Drop Machine
GE Cable/Car Cable Plum blossom barrel drop machine
The machine is suitable for square/circular carton packing of flexible wire such as vehicle wire and electronic wire. This equipment can be used for reverse winding alone, and can also be used in linkage with extrusion line. The production efficiency is high, and the line falling with special vibration device is orderly and not disorderly.
This equipment has a high degree of automation, a user-friendly operation interface that is convenient and fast, automatic barrel change, with an external spark machine, bump meter that can automatically eliminate waste lines.
GE wire/automotive wire plum blossom barrel drop machine wire collection technical specification book
Usage: this machine is suitable for square or round paper drums and cartons of plum packaging
Main accessories brand: all electrical appliances, and bearings using famous brands
1. Motor: Constant speed AC motor
2. Controller: Japan Yaskawa 415V inverter;
3. Programmable design controller: Delta;
4. Electrical appliances; all electrical appliances adopt the Chint and Shilin brands;
5. Bearing: Harbin; NSK
Product Parameters

Product Parameters
Model	Wire Diameter	Bucket Size	Max Weight	Color
ML400	φ2-6mm	500mm	75-100kg	Grey
Speed	Motor	Forming style	PLC	Automatic
400m/min	4KW	Quincunx	Taida	Yes

Detailed Photos
Main Specifications And Performance:
1. Applicable outer diameter: Ф2mm-Ф6.0mm;
2. Height of packaging and conveying platform: 350mm;
3. Outer dia: 500mm, high 400-500mm, weight 75-100kg.
The Equipment Composition Specifications
Adaptable wire diameter: MaxФ2-Ф6 mm (soft wire).
Adapt line speed: adapt to speed max300m/min;
Power: 4KW AC motor, three-phase 380V voltage.
Molding pattern: overlapping plum blossom shape.
Property-1
Vibration device: by a 1/2hp gear motor, control the vibration platform, and improve the amount of cable barrel, the cable through the vibration will be more encrypted, reducing transportation loss.
Adapt to falling barrel: outer barrel inner diameter 575mm× inner barrel outer diameter 300mm× height 585mm. (or other non-standard sizes)
Property-2
Meter meter forecast function and meter meter to automatic barrel change, storage line, manual waste line elimination control.
Threading method: Can achieve rapid stringing.
This machine is suitable for round wire plum blossom type into barrels, easy to put the line in the post-sequence such as cutting and peeling, etc., will not be knotted, and adapts to the highest cutting speed of 10m/s.
Specification
Weight: 2000kg.
Operation direction: customized according to customer requirements.
Machine color: off-white.
5.Ф500 Plum blossom barrel receiver auxiliary parts:
Match auxiliary inlet guide frame and steering mechanism.
6. Device picture
FAQ
1. Can the φ630mm Shaftless Wire Take-up Machine handle wires of different thicknesses?
Yes, the machine can handle wires of different thicknesses.
2. Does the machine come with a warranty?
Yes, the machine comes with a standard warranty from the date of purchase.
3. What is the average life of the machine?
The average life of the machine depends on usage, but if properly maintained, it can last for several years.
4. Can the machine operate continuously?
The machine is designed for continuous operation and is ideal for high-volume production facilities.
5. Is the machine easy to operate?
Yes, the φ630mm Shaftless Wire Take-up Machine is easy to operate, with a user-friendly interface and simple operation.
