X6325 Series Knee Type CNC Milling Machine
| US$50,000.00-100,000.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
X6325
Controlling Mode
CNC
Automatic Grade
Automatic
Precision
High Precision
Certification
GS
Condition
New
Transport Package
Woodencase
Origin
China
Production Capacity
1000pieces/Year
Product Description
Product DescriptionProduct Parameters
| ltem | UNIT | X6325 | X6325A | X6325B | X6325C | X6325D |
| Table size | mm | 254×1270(10×50") 254×1370(10×54") | 254×1270(10×50") | 254×1370(10×54") | ||
| T slot size | mm | 3×16 | 3×16 | |||
| X axis travel | mm | 820/ 920 | 800 / 900 | 820 / 920 | 820 / 920 | |
| Y axis travel | mm | 410 | 380 | 410 | ||
| Zaxis travel | mm | 400 | 350 | 400 | ||
| Ram cross travel | mm | 470 | 470 | |||
| Distance from spindle nose to table | mm | 0~400 | 0~400 | |||
| Spindle hole taper | Standar R8 (optional NT30/40) | NT40 | ||||
| Quill travel | mm | 127 | 127 | |||
| Spindle speed | r/min | Standard 16 shift: 65-4500(50HZ)80-5440(60HZ) Optional Variable speed: 60-4200 | Standard 16 shift: 65-4500(50HZ) 80-5440(60HZ) Optional Variable speed: 65-3750 | |||
| Auto quill feed | mm/rev | 0.04(0.0015")/0.08(0.003")/0.15(0.006") | 0.04(0.0015")/0.08(0.003")/0.15(0.006") | |||
| Spindle motor power | HP | 3(2.2KW) | 5(3.75KW) | |||
| Milling head swivel | ±90° | ±90° | ||||
| Milling head tilting | ±45° | FIX | ±45° | |||
| 1 miller/pallet | mm | 1516×1550×2080 | 1516×1550×2080 | |||
| 2 miller/pallet | mm | 1650×1790×2170 | 1650×1790×2170 | |||
| 3 miller/pallet | mm | 1650×2185×2235 | 1650×2185×2235 | |||
| G.W/set | kg | 1320 | 1280 | 1300 | 1490 | |
