1700mm ABC 3 Layers Film Blowing Machine
| US$60,000.00-80,000.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
FM3-1700
Maximum Folding Width of Film
1600mm
Screw Diameter
65mm*3
Automation
Automatic
Computerized
Computerized
Machine Weight
10T
Certification
CE, ISO9001:2008
Machine Size
L*W*H: 6.5m * 3.45* 6.5m
Voltage
380V 50Hz 3phase
Transport Package
Plastic Warp Film for Container Shipment
Specification
3 layers
Trademark
Xiongqiu Plastic Machinery Co., Ltd.
Origin
Foshan, Guangdong Province
HS Code
8477300000
Product Description
Extruder can provide a good plastic effect and a high quality products. It is designed optimizedly in die head and the flow is designed scientificly and rationlly.Widely used in producing composite membrane, cable film, macromolecule adhesive film, liquid film, agricultural film and shrinkable film.
| Model | FM3-1300 | FM3-1700 | FM3-2000 | FM3-2200 |
| suitable material | HDPE | |||
| thickness | 0.02--0.20mm | |||
| film width | 1200mm | 1600mm | 1900mm | 2100mm |
| max output | 80kgs/hr | 105kgs/hr | 150kgs/hr | 215kgs/hr |
Extruder
| screw diameter | Φ45mm*3 | Φ55mm*3 | Φ65mm*3 | Φ75mm*3 |
| L/D ratio | 30:1 | |||
| temp. controller | 15 zone | 15 zone | 16 zone | 16 zone |
| barrel cooling | 120w*4 | 120w*4 | 120w*6 | 120w*6 |
| driving motor | 11kw*3 | 15kw*3 | 18.5kw*3 | 30kw*3 |
Die head
| die diameter | Φ250mm | Φ350mm | Φ450mm | Φ630mm |
| air ring diameter | Φ350mm | Φ450mm | Φ550mm | Φ900mm |
| die structure | Spiral mandrel die chrome plated surface 40Cr | |||
| cooling fan | 2.2kw | 3kw | 4kw | 5.5kw |
Take up part
| take up width | 1300mm | 1700mm | 2000mm | 2200mm |
| effective width | 1200mm | 1600mm | 1900mm | 2100mm |
| take up motor | 1.5kw | 2.2kw | 2.2kw | 3.7kw |
winder
| winder width | 1300mm | 1700mm | 2000mm | 2200mm |
| effective width | 1200mm | 1600mm | 1900mm | 2100mm |
| winder motor | 1.5kw | 2.2kw | 3.7kw | 3.7kw |
| optional equipment | auto-loader device, film surface treater, air compressor, fast change net, automatic winder, double wind air ring, IBC inner cooling die head | |||
PICTURES FOR REFERENCE:
